Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Mean Well RSP-150-13.5 Power Supply 150W 13.5V 11.2A

1U low profile with active PFChigh efficiency

SKU RSP-150-13.5

Log in to see price Trade pricing & online ordering for account holders

Select model — 5 in this family

RSP-150-13.5

RSP-75-13.5 75W 13.5V Backorder

RSP-100-13.5 100W 13.5V Backorder

RSP-150-13.5 150W 13.5V Low stock

RSP-200-13.5 200W 13.5V Backorder

RSP-320-13.5 320W 13.5V Backorder

Product variants

Notify me when it's back in stock

EN55022(CISPR22) Class B,EN61000-3-2,-3, GB9254 class B,EN61000-4-2,3,4,5,6,8,11,EN55024

Key Features

✓Universal AC input / Full range
✓Built-in active PFC function
✓Built-in constant current limiting circuit
✓Protections:Short circuit/ Overload / Over voltage / Over temperature
✓Cooling by free air convection
✓1U low profile 30mm
✓Remote ON-OFF control
✓LED indicator for power on
✓100% full load burn-in test
✓3 years warranty

Frequently Asked Questions

When would a designer choose the RSP-150-13.5 over the RSP-150-12 or RSP-150-15?

The RSP-150-13.5 provides 13.5V at 11.2A (151.2W), positioned between the 12V (12.5A) and 15V (10A) options. A 13.5V output is appropriate for battery float charging of 12V lead-acid batteries, certain motor controllers with mid-range voltage requirements, and telecom auxiliary circuits that specify a 13.5V nominal supply.

How does the RSP-150-13.5 compare to the RSP-100-13.5?

The RSP-100-13.5 delivers 13.5V at 7.5A (101.25W) in a 179.0 × 99.0 × 30.0 mm chassis. The RSP-150-13.5 delivers 13.5V at 11.2A (151.2W) in a 199.0 × 99.0 × 30.0 mm chassis. If your 13.5V load requires more than 7.5A, the RSP-150-13.5 is the appropriate upgrade. The RSP-150-13.5 also adds c_rcm certification for the Australia/New Zealand market.

Can the RSP-150-13.5 operate in an outdoor enclosure in a cold climate?

The RSP-150-13.5 is rated from -30°C to +70°C ambient. For outdoor deployment, it must be housed in a sealed enclosure with an appropriate IP rating, since the unit itself has no IP ingress protection. The -30°C lower limit supports cold-climate operation when the enclosure maintains this minimum.

What certifications does the RSP-150-13.5 hold?

The RSP-150-13.5 holds BSMI, CB, CCC, CE, EAC, c_rcm, TÜV, and UL certifications. This covers Taiwan, China, Europe, North America, Australia/New Zealand, and the Eurasian Economic Union.

What is the form factor of the RSP-150-13.5 and is it rack-mountable?

The RSP-150-13.5 measures 199.0 × 99.0 × 30.0 mm (30 mm height, 1U profile) and weighs 0.6 kg. It fits in a standard 1U rack space and can be mounted alongside other 1U equipment in 19-inch cabinets.
