Mean Well SMT01C-12 DC-DC Converter - 1W - 36~72V in 12V out
Please Login for Pricing
Description
Description
Features
| SMD package with industry-standard pinout |
| 2:1 wide input range |
| Operating temperature range -40~+90℃ |
| Comply to BS EN/EN55032 radiated Class A without additional components |
| Optional reel packing |
| Protections: Short circuit(Continuous)/Overload |
| 1.5KVDC I/O isolation |
| 3 years warranty |
General Specification
| Voltage accuracy | ±2.0% |
| Overload Protection | 130~200% rated output power |
| Cooling | Free-air convection |
| Short circuit protection | Continuous, automatic recovery |
| Working temperature | -40 ~ +90℃ (Refer to "Derating Curve") |
| EMC | Compliance to EN55032 class A, EN61000-4-2,3,4,5,6,8 |
| Temp. Coefficient | 0.03% / ℃ (0 ~ 85℃) |
| Dimension (LxWxH) (mm) | 15.24*10.9*7.1mm (0.6*0.43*0.28 inch) |
| Potting material | UL 94V-0 rated |
Specifications
Specifications
-
BrandMean Well
-
SeriesSMT Series
-
Power Rating1 Watt
-
Output Voltage12 Volt
-
Rated Current0.08 Ampere
-
Input Voltage36V~72V
-
Standards MetCE,EMC
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~90°C
-
Warranty3 Year
-
Length1.52 cm
-
Width1.09 cm
-
Height0.71 cm
-
Weight0 kg
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Other SMT01 Models
8 other models| Model | Power | Voltage | Current | IP Rating | |
|---|---|---|---|---|---|
| Mean Well SMT01C-15 DC-DC Converter - 1W - 36~72V in 15V out | 1W | 15V | 0.06A | — | View |
| Mean Well SMT01C-05 DC-DC Converter - 1W - 36~72V in 5V out | 1W | 5V | 0.2A | — | View |
| Mean Well SMT01B-15 DC-DC Converter - 1W - 18~36V in 15V out | 1W | 15V | 0.06A | — | View |
| Mean Well SMT01B-12 DC-DC Converter - 1W - 18~36V in 12V out | 1W | 12V | 0.08A | — | View |
| Mean Well SMT01B-05 DC-DC Converter - 1W - 18~36V in 5V out | 1W | 5V | 0.2A | — | View |
| Mean Well SMT01A-15 DC-DC Converter - 1W - 9~18V in 15V out | 1W | 15V | 0.06A | — | View |
| Mean Well SMT01A-12 DC-DC Converter - 1W - 9~18V in 12V out | 1W | 12V | 0.08A | — | View |
| Mean Well SMT01A-05 DC-DC Converter - 1W - 9~18V in 5V out | 1W | 5V | 0.2A | — | View |
{
