Introduction
Following the success of the NTS/NTU series (250–3200W) off-grid DC-AC unidirectional inverters—well-received globally with thousands sold annually—MEAN WELL now introduces the NTN-5K Series, a next-generation 5KW true sine wave inverter with a built-in AC-DC charging function.
This high-performance, all-in-one solution integrates AC-DC charging, DC-AC inversion, and AC bypass in a single compact unit. It also supports external solar panels and MPPT chargers, making it a versatile choice for industrial and mobile power applications.
Top 5 Highlights
- High-Speed Charging: Built-in 4520W AC-DC charger for rapid energy replenishment.
- Scalable Output: Modular 5KW units can be paralleled up to 30KW (1+5 configuration), offering flexible power scaling.
- Rack-Friendly Design: 2U chassis fits standard 19" cabinets for fast and easy installation.
- Three-Phase Support: Combine three units to output 3Ø4W AC power.
- Smart Monitoring: Includes support for CMU2E and CMU2E-R monitoring platforms for full control.
MEAN WELL also offers one-stop services for related components such as batteries, fans, and cabinets, helping system integrators quickly build off-grid energy storage systems, mobile charging stations, or backup power solutions.
Additional Features
- Pure sine wave output (THD <3%)
- Instantaneous peak output up to 10KW
- Built-in Modbus/CAN bus for communication
- Adjustable output voltage, frequency, and energy-saving modes
- Compatible with lead-acid and lithium batteries
- Full protections: input/output voltage, temperature, reverse polarity, overload, short circuit, etc.
- -30°C to +70°C wide temperature range for indoor and outdoor use
- Durable design with PCB coating for dust/moisture/dirt protection
- 5-year warranty and global certifications: CB / TUV / RCM / EAC / CE / UKCA / FCC
Applications
Perfect for indoor backup and off-grid scenarios such as:- Homes and offices during power outages
- Remote sites, cabins, and boats
- Construction sites and mobile power stations
- Equipment like computers, refrigerators, lighting, tools, and more
Product Information
If you are interested, please feel free to contact us at contact@wellforces.co.nz.
