Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Mean Well PA-120P-54P Portable Battery Chargers 121.44W 55.2V 2.2A - Single Output Power Supply

SKU:

PA-120P-54P

Log in to see price Trade pricing & online ordering for account holders

Notify me when it's back in stock

Features

AC input range selected by switch

Built-in passive PFC function compliance to EN61000-3-2

With AC ON-OFF switch

3 poles AC inlet with fuse holder

Protections: Short circuit / Overload / Over voltage / Over temperature

Charger type can be selected (Optional)

Charger for lead-acid batteries

2 color LED loading indicator

Open frame models available (Without safety approval)

Low cost, High reliability

2 years warranty

General Specification

AC input voltage range	88~132VAC / 176~264VAC(selectable by switch); 248~370VDC
AC inrush current (max.)	Cold start, 50A at 230VAC
Overload protection	90%~110% Constant current limiting, auto-recovery
Over voltage protection	108%~127% hiccup mode,auto-recovery
Setup, rise, hold up time	1000ms,50ms,16ms at full load
Withstand voltage	I/P-O/P: 3kVAC, I/P-FG: 2kVAC, O/P-FG: 0.5kVAC
Working temperature	-10~+45ºC(refer to output derating curve)
Safety standards	UL60950-1,TUV EN60950-1,EN60335,EN60335-1,EN60335-2-29 approved
EMC standards	EN55022(CISPR22) Class B,EN61000-3-2,-3,EN61000-4-2,3,4,5,6,8,11,EN55024
Dimension (LxWxH) (mm)	Case Type:180x96x 49mm;PCB:144x90x 33mm
Packing	16pcs / 17.9kg(without PFC); 16pcs / 20.1kg(with PFC)

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Model	Power	Battery Type	Battery Voltage	Charging Current
Mean Well PA-120P-13C Portable Battery Chargers 99.36W 13.8V 7.2A - Single Output Power Supply	99.36W	Lead Acid Battery	12V	—	View
Mean Well PA-120P-54C Portable Battery Chargers 121.44W 55.2V 2.2A - Single Output Power Supply	121.44W	Lead Acid Battery	48V	—	View
Mean Well PA-120P-27P Portable Battery Chargers 118.68W 27.6V 4.3A - Single Output Power Supply	118.68W	Lead Acid Battery	24V	—	View
Mean Well PA-120P-27C Portable Battery Chargers 118.68W 27.6V 4.3A - Single Output Power Supply	118.68W	Lead Acid Battery	24V	—	View
Mean Well PA-120P-13P Portable Battery Chargers 99.36W 13.8V 7.2A - Single Output Power Supply	99.36W	Lead Acid Battery	12V	—	View
