Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

ENVO ENC-12-300 Dimmable LED Driver 7.5W-12W 300mA Constant Current

SKU ENC-12-300

Log in to see price Trade pricing & online ordering for account holders

Select model — 3 in this family

ENC-12-300

ENC-12-300 12W 300mA In stock

ENC-16-700 16W 700mA In stock

ENC-18-500 18W 500mA In stock

Product variants

In stock

Overview

Features

Dimmable (AC Phase Cut)
Large screw terminal connection
Low Cost, High Reliability
Isolation class II
Cooling by free air convection
Protections: Short Circuit / Over Temperature
2 years warranty

Specifications

ENC-12-300Specifications from the official datasheetDownload datasheet PDF

300mA Models

SKU: ENC-12-300
Wattage: 12W
Current: 350mA
Min. Load: 7.5W
Dimension(mm): 129 x 44 x 28

Certifications & ratings

Certification marks: CE, RoHS

Downloads

Datasheet1

ENC-12-300 datasheetENC_converted.pdf PDF Download

FAQ

What type of LED driver is the ENVO ENC-12-300?

The ENVO ENC-12-300 is a constant current LED driver rated at 300mA. It is designed for LED loads within the ENC series operating range and supports 7.5W to 12W output.

Is the ENVO ENC-12-300 dimmable?

Yes, this model supports AC phase cut dimming. That makes it suitable for applications where a dimmable constant current driver is required for compatible LED fixtures or modules.

What output and power rating does this driver provide?

This model is rated for 12W maximum power with a 300mA constant current output. The listed output voltage is 40V, making it appropriate for products designed to operate with this driver specification.

What kinds of applications is the ENC-12-300 best suited for?

The ENC-12-300 is intended for constant current LED applications that need a 300mA dimmable driver. It is a practical choice for commercial or trade buyers looking for a low cost, high reliability driver in the 7.5W to 12W range.

Can this driver be used in demanding temperature conditions?

This model is rated for operation from -20°C to 55°C. That range makes it suitable for many indoor and controlled-environment lighting applications, provided the overall installation stays within those limits.

What protection features and warranty does the ENVO ENC-12-300 include?

According to the product details, this driver includes short circuit protection and over temperature protection. It also comes with a 2-year warranty.
