What type of LED driver is the ENVO ENC-12-300?

The ENVO ENC-12-300 is a constant current LED driver rated at 300mA. It is designed for LED loads within the ENC series operating range and supports 7.5W to 12W output.

Is the ENVO ENC-12-300 dimmable?

Yes, this model supports AC phase cut dimming. That makes it suitable for applications where a dimmable constant current driver is required for compatible LED fixtures or modules.

What output and power rating does this driver provide?

This model is rated for 12W maximum power with a 300mA constant current output. The listed output voltage is 40V, making it appropriate for products designed to operate with this driver specification.

What kinds of applications is the ENC-12-300 best suited for?

The ENC-12-300 is intended for constant current LED applications that need a 300mA dimmable driver. It is a practical choice for commercial or trade buyers looking for a low cost, high reliability driver in the 7.5W to 12W range.

Can this driver be used in demanding temperature conditions?

This model is rated for operation from -20°C to 55°C. That range makes it suitable for many indoor and controlled-environment lighting applications, provided the overall installation stays within those limits.

What protection features and warranty does the ENVO ENC-12-300 include?

According to the product details, this driver includes short circuit protection and over temperature protection. It also comes with a 2-year warranty.

Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Envo

ENVO ENC-12-300 Dimmable LED Driver 7.5W-12W 300mA Constant Current

SKU ENC-12-300

Log in to see price Trade pricing & online ordering for account holders

Select model — 3 in this family

ENC-12-300

ENC-12-300 12W 300mA In stock

ENC-16-700 16W 700mA In stock

ENC-18-500 18W 500mA In stock

Product variants

Notify me when it's back in stock

The ENC-12-300 is a 12W ENVO AC-DC constant current LED driver (input: 200~250VAC, output: 40V, operating temperature: -20~+55°C).

Key Features

✓ Input voltage: 200~250VAC
✓ Output voltage (max): 40V
✓ Rated output current: 300mA
✓ TRIAC (phase-cut) dimmable
✓ Operating temperature: -20~+55°C
✓ Safety certifications: CB, CE, RoHS, SAA
✓ 2 year warranty
