What systems benefit from the RSP-2400-48's 48V, 50A output?

The RSP-2400-48 provides 2400W at 48V with 50A output, suitable for powering telecom DC power systems, PoE aggregation equipment, and high-capacity battery charging applications. The 48V bus is a common standard in telecommunications and data center power distribution.

Is the RSP-2400-48 suitable for low-temperature environments?

The RSP-2400-48 operates down to -20°C, making it appropriate for heated indoor enclosures in cold climates but not for unheated outdoor installations. Its upper limit is +70°C, matching the range of other RSP-2400 series units.

How does the RSP-2400-48 compare to the RSP-2000-48 and RSP-3000-48?

The RSP-2000-48 provides 2016W and 42A on a wide 90-264VAC input. The RSP-2400-48 steps up to 2400W and 50A, and the RSP-3000-48 reaches 3000W and 62.5A — both requiring a narrower 180-264VAC input. All three share 48V output; the RSP-2000-48 alone supports low-line AC.

What efficiency and paralleling capability does the RSP-2400-48 offer?

The RSP-2400-48 achieves up to 91.5% efficiency and supports 2+1 active current sharing for N+1 redundancy. It weighs 3.3 kg and measures 278.0 × 177.8 × 63.5 mm.

Mean Well RSP-2400-48 Power Supply 2400W 48V - Buy Now!

The RSP-2400 is a 2400W Mean Well power converter (input range: 180~264VAC).

Key Features

✓ Input voltage range: 180~264VAC
✓ DC output voltage adjustable ±10%
✓ 3KVAC reinforced I/O isolation
✓ Protections: Overload / Over voltage / Over temperature
✓ Active PFC — meets international energy efficiency regulations
✓ Remote ON/OFF control
✓ Safety approvals: UL62368-1, TUV EN62368-1, EAC TP TC 004, BSMI CNS14336-1
✓ 3 years warranty

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Model	Power	Voltage	Current
Mean Well RSP-2400-24 Power Supply 2400W 24V 100A	2400W	24V	100A	View
Mean Well RSP-2400-12 Power Supply 2000W 12V 166.7A	2000.4W	12V	166.7A	View

Please log in to write a review.

{ "id":8343941415211, "variants" :[{ "context":"default", "variant_id": 45321497936171, "sku":"RSP-2400-48", "inventory_qty" : 0, "customer" :false, "custom_html" :"\u003ca class=\"text-current logged-out-price logged-out\" href=\"https:\/\/wellforces.co.nz\/customer_authentication\/redirect?locale=en\u0026region_country=NZ\"\u003e\n \u003cspan \u003ePlease \u003c\/span\u003e \u003cspan class=\"login-text\"\u003eLogin\u003c\/span\u003e \u003cspan\u003e for Pricing\u003c\/span\u003e\n \u003c\/a\u003e", "volume_html" :"\u003cvolume-pricing class=\"parent-display inside_product_form\" id=\"volume-pricing-main\" \u003e\u003c\/volume-pricing\u003e" } ] }

Key Features

✓ Input voltage range: 180~264VAC

✓ DC output voltage adjustable ±10%

✓ 3KVAC reinforced I/O isolation

✓ Protections: Overload / Over voltage / Over temperature

✓ Active PFC — meets international energy efficiency regulations

✓ Remote ON/OFF control

✓ Safety approvals: UL62368-1, TUV EN62368-1, EAC TP TC 004, BSMI CNS14336-1

✓ 3 years warranty

Mean Well RSP-2400-48 Power Supply 2400W 48V 50A
