What is the RSP-2400-24 suited for in industrial automation?

The RSP-2400-24 supplies 24V at 100A (2400W), which matches the bus voltage used in many PLC systems, servo amplifiers, and industrial robot controllers. Its 5-year warranty and UL/CE/TÜV certifications support deployment in regulated industrial environments.

Can the RSP-2400-24 operate in a wide range of ambient temperatures?

The RSP-2400-24 is rated for -20°C to +70°C ambient operation. It is designed for indoor use and does not carry an IP rating for outdoor or wash-down environments.

How does the RSP-2400-24 differ from the RSP-3000-24?

The RSP-2400-24 and RSP-3000-24 share the same 278.0 × 177.8 × 63.5 mm enclosure and both require 180-264VAC input. The RSP-2400-24 delivers 2400W at 100A, while the RSP-3000-24 increases output to 3000W at 125A. Both feature 2+1 active current sharing.

What input voltage does the RSP-2400-24 require?

The RSP-2400-24 accepts 180-264VAC input only, which means it is not suitable for standard 100-120V North American wall outlets. It is intended for 200V-class industrial AC power systems.

Mean Well RSP-2400-24 Power Supply 2400W 24V - Buy Now!

The RSP-2400 is a 2400W Mean Well power converter (input range: 180~264VAC).

Key Features

✓ Input voltage range: 180~264VAC
✓ DC output voltage adjustable ±10%
✓ 3KVAC reinforced I/O isolation
✓ Protections: Overload / Over voltage / Over temperature
✓ Active PFC — meets international energy efficiency regulations
✓ Remote ON/OFF control
✓ Safety approvals: UL62368-1, TUV EN62368-1, EAC TP TC 004, BSMI CNS14336-1
✓ 3 years warranty

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Model	Power	Voltage	Current
Mean Well RSP-2400-48 Power Supply 2400W 48V 50A	2400W	48V	50A	View
Mean Well RSP-2400-12 Power Supply 2000W 12V 166.7A	2000.4W	12V	166.7A	View

Please log in to write a review.

{ "id":8343941218603, "variants" :[{ "context":"default", "variant_id": 45321495281963, "sku":"RSP-2400-24", "inventory_qty" : 0, "customer" :false, "custom_html" :"\u003ca class=\"text-current logged-out-price logged-out\" href=\"https:\/\/wellforces.co.nz\/customer_authentication\/redirect?locale=en\u0026region_country=NZ\"\u003e\n \u003cspan \u003ePlease \u003c\/span\u003e \u003cspan class=\"login-text\"\u003eLogin\u003c\/span\u003e \u003cspan\u003e for Pricing\u003c\/span\u003e\n \u003c\/a\u003e", "volume_html" :"\u003cvolume-pricing class=\"parent-display inside_product_form\" id=\"volume-pricing-main\" \u003e\u003c\/volume-pricing\u003e" } ] }

Key Features

✓ Input voltage range: 180~264VAC

✓ DC output voltage adjustable ±10%

✓ 3KVAC reinforced I/O isolation

✓ Protections: Overload / Over voltage / Over temperature

✓ Active PFC — meets international energy efficiency regulations

✓ Remote ON/OFF control

✓ Safety approvals: UL62368-1, TUV EN62368-1, EAC TP TC 004, BSMI CNS14336-1

✓ 3 years warranty

Mean Well RSP-2400-24 Power Supply 2400W 24V 100A
