Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Mean Well MPQ-200C Power Supply 200W 5V 15V -5V -15V 12A

Q: Can I use the MPQ-200C for equipment that needs 5V plus positive and negative 15V rails?

This model is identified in the product name as a 200W constant voltage supply with 5V, 15V, -5V, and -15V outputs. That makes it relevant for equipment designed around that specific rail combination rather than the 12V and -12V arrangement of the B version. The main listed output is 5V at 12A, with a total power rating of 200W.

Q: Is the MPQ-200C a good fit for embedded or analog-heavy systems that need multiple DC voltages?

It is a multi-output power supply, which is useful where one piece of equipment needs several DC rails from one source. For designs that specifically require 5V, 15V, -5V, and -15V, the C version is the directly matched option in the provided data. Its wide 90-264VAC input also supports deployment across varied AC mains conditions.

Q: Can the MPQ-200C be used in medical or lab equipment with strict leakage concerns?

The product is medical safety approved and specifies extremely low leakage current below 150 uA. Those are relevant attributes for medical or laboratory equipment selection where leakage current matters. The unit is rated for 200W total and weighs 0.66 kg.

Q: Would this model work for OEM equipment sold into different mains regions?

Its input range is 90-264VAC, which supports a broad AC supply range for international equipment designs. That is useful for OEM products that may be used on different mains systems without changing the power supply family. On the DC side, this remains the C version with 5V, 15V, -5V, and -15V outputs named in the product title.

Q: Is the MPQ-200C suitable for outdoor environments or only controlled enclosures?

The listed operating temperature range is -20C to +70C, which provides temperature guidance for equipment use. No IP rating is included in the supplied specs, so the product data does not confirm outdoor or moisture-exposed installation. Based on the provided information, temperature range is specified but ingress protection is not.

Q: How does the MPQ-200C differ from the other MPQ models shown?

The sibling list includes MPQ-120B, MPQ-120C, MPQ-120D, MPQ-120E, MPQ-200B at 200W and 5V 12A, MPQ-200D at 200W and 5V 12A, and MPQ-200F at 200W and 5V 15A. The MPQ-200C is the 200W C version, with the product name specifying 5V, 15V, -5V, and -15V outputs. In the published ratings shown here, B, C, and D share a listed 5V 12A main output, while F increases that listed 5V output to 15A.

extremely low leakage current

SKU:

MPQ-200C

Log in to see price Trade pricing & online ordering for account holders

Notify me when it's back in stock

<150 μA/264VAC

Key Features

✓Universal AC input/Full range
✓Low leakage current < 150μA
✓Protections: Short circuit/Overload/Over voltage/Over temperature
✓Free air convection for 140W and forced air convection for 200W
✓Medical safety approved(2 x MOPP between primary to secondary)
✓With power good and fail signal output
✓Built-in remote ON-OFF control
✓Built-in remote sense function
✓Fixed switching frequency at 100KHz
✓3 years warranty

Frequently Asked Questions

Can I use the MPQ-200C for equipment that needs 5V plus positive and negative 15V rails?

This model is identified in the product name as a 200W constant voltage supply with 5V, 15V, -5V, and -15V outputs. That makes it relevant for equipment designed around that specific rail combination rather than the 12V and -12V arrangement of the B version. The main listed output is 5V at 12A, with a total power rating of 200W.

Is the MPQ-200C a good fit for embedded or analog-heavy systems that need multiple DC voltages?

It is a multi-output power supply, which is useful where one piece of equipment needs several DC rails from one source. For designs that specifically require 5V, 15V, -5V, and -15V, the C version is the directly matched option in the provided data. Its wide 90-264VAC input also supports deployment across varied AC mains conditions.

Can the MPQ-200C be used in medical or lab equipment with strict leakage concerns?

The product is medical safety approved and specifies extremely low leakage current below 150 uA. Those are relevant attributes for medical or laboratory equipment selection where leakage current matters. The unit is rated for 200W total and weighs 0.66 kg.

Would this model work for OEM equipment sold into different mains regions?

Its input range is 90-264VAC, which supports a broad AC supply range for international equipment designs. That is useful for OEM products that may be used on different mains systems without changing the power supply family. On the DC side, this remains the C version with 5V, 15V, -5V, and -15V outputs named in the product title.

Is the MPQ-200C suitable for outdoor environments or only controlled enclosures?

The listed operating temperature range is -20C to +70C, which provides temperature guidance for equipment use. No IP rating is included in the supplied specs, so the product data does not confirm outdoor or moisture-exposed installation. Based on the provided information, temperature range is specified but ingress protection is not.

How does the MPQ-200C differ from the other MPQ models shown?

The sibling list includes MPQ-120B, MPQ-120C, MPQ-120D, MPQ-120E, MPQ-200B at 200W and 5V 12A, MPQ-200D at 200W and 5V 12A, and MPQ-200F at 200W and 5V 15A. The MPQ-200C is the 200W C version, with the product name specifying 5V, 15V, -5V, and -15V outputs. In the published ratings shown here, B, C, and D share a listed 5V 12A main output, while F increases that listed 5V output to 15A.

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Model	Power	Voltage	Current
Mean Well MPQ-200F Power Supply 200W 5V 24V 15V -15V 15A	200W	5V	15A	View
Mean Well MPQ-200D Power Supply 200W 5V 24V 12V -12V 12A	200W	5V	12A	View
Mean Well MPQ-200B Power Supply 200W 5V 12V -5V -12V 12A	200W	5V	12A	View
