Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Mean Well PWM-120-12KN AC-DC Single output LED driver Constant Voltage (CV) 10A

constant voltage PWM style outputbuilt-in active PFC functionstandby power consuption

SKU:

PWM-120-12KN

Log in to see price Trade pricing & online ordering for account holders

Notify me when it's back in stock

The PWM-120 is a 120W Mean Well DIN rail power converter with a 191mm profile (input range: 90~305VAC, operating temperature: -40~+80℃).

Key Features

✓ 191mm width — DIN rail TS-35 compatible
✓ Input voltage range: 90~305VAC
✓ 3.75KVAC reinforced I/O isolation
✓ Cooling by free air convection
✓ Wide operating temperature: -40~+80℃
✓ Protections: Short circuit / Overload / Over voltage / Over temperature
✓ Active PFC — meets international energy efficiency regulations
✓ Safety approvals: Note.5 UL8750( type ”HL” )(except for 12DA type), CSA C22.2 No. 250.13-12; ENEC EN61347-1, EN61347-2-13,EN62384 independent, IP67,BIS IS15885( for PWM-120-12,24 only), EAC TP TC 004,GB19510.1,GB19510.14
✓ 3 years warranty

Frequently Asked Questions

Can I use the PWM-120-12KN to control 12V LED lighting directly from a KNX building automation system?

Yes. The PWM-120-12KN has a built-in KNX interface, allowing direct integration into KNX building automation networks without requiring a separate KNX-DALI gateway. It outputs 12V at 10A (120W) with a constant voltage PWM-style output compatible with 12V LED strips.

Is the PWM-120-12KN suitable for outdoor or covered wet-area LED lighting installations?

Yes. The IP67 rating makes the PWM-120-12KN suitable for outdoor enclosures and covered locations exposed to rain or moisture. Its -40°C to +90°C operating temperature range also covers demanding outdoor climates.

How many meters of 12V LED strip can the PWM-120-12KN drive?

The PWM-120-12KN supplies up to 120W at 12V. For a 10W/m LED strip that is approximately 12 meters (120 ÷ 10); for a 14.4W/m strip, approximately 8.3 meters (120 ÷ 14.4). Confirm your strip's rated power per meter and apply a 20% derating buffer.

Does the PWM-120-12KN require an external gateway to work on a KNX network?

No. The KNX interface is built into the driver, so no external KNX-DALI gateway is needed. This simplifies panel wiring and reduces the number of components in KNX lighting control installations.

Can the PWM-120-12KN be used for 12V LED strip lighting in a hotel corridor managed by a KNX system?

Yes. The PWM-120-12KN is designed for this type of application, providing 120W of 12V constant voltage output with direct KNX control. Smooth PWM-style dimming is compatible with 12V LED strip lighting commonly used in hospitality corridor and accent lighting.

How does the PWM-120-12KN's standby power compare to the standard PWM-120-12?

The PWM-120-12KN specifies a standby power consumption of less than 0.5W, which is beneficial in large building installations where many drivers may be in standby. The standard PWM-120-12 does not publish this standby figure; it uses a 3-in-1 dimming interface rather than KNX.

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Model	Power	Voltage	Current	IP Rating
Mean Well PWM-120-24DA2 Power Supply 120W 24V DALI2 5A	120W	24V	5A	IP67	View
Mean Well PWM-120-24DA Power Supply 120W 24V - DALI 5A	120W	24V	5A	IP67	View
Mean Well PWM-120-12DA2 Power Supply 120W 12V DALI2 10A	12W	12V	10A	IP67	View
Mean Well PWM-120-48DA Power Supply 120W 48V - DALI 2.5A	120W	48V	2.5A	IP67	View
Mean Well PWM-120-48 Power Supply 120W 48V - Dimmable 2.5A	120W	48V	2.5A	IP67	View
Mean Well PWM-120-36DA Power Supply 120W 36V - DALI 3.4A	120W	36V	3.4A	IP67	View
Mean Well PWM-120-36 Power Supply 120W 36V - Dimmable 3.4A	120W	36V	3.4A	IP67	View
Mean Well PWM-120-24KN AC-DC Single output LED driver Constant Voltage (CV) 5A	120W	24V	5A	IP67	View
Mean Well PWM-120-24BLE AC-DC Single output LED driver Constant Voltage (CV)	120W	24V	5A	—	View
Mean Well PWM-120-24 Power Supply 120W 24V - Dimmable 5A	120W	24V	5A	IP67	View
