Can I use the SMU02M-05 to derive 5V for embedded controllers from a 10-13VAC source?

This model is intended for low-power conversion to a 5V constant-voltage output from a 10-13VAC input range. At 2W, it is better suited to embedded controllers, logic sections, or compact interface boards than heavier-load devices.

Is the SMU02M-05 appropriate for low-power industrial monitoring or automation boards?

It can fit low-power automation or monitoring electronics that need a regulated 5V rail and stay within the 2W rating. The small 11.6 × 10.14 × 7.5 mm size is useful where PCB space is limited in compact industrial assemblies.

Would the SMU02M-05 work in portable or space-constrained electronics?

Yes, its 0.0013 kg weight and 11.6 × 10.14 × 7.5 mm dimensions make it suitable for very compact electronic designs. The main fit is low-power 5V circuitry rather than applications needing more than 2W.

Is the SMU02M-05 suitable for outdoor equipment cabinets or harsh environments?

The operating temperature range is -40°C to +85°C, so it is specified for broad temperature conditions. No IP rating is listed, which means the provided specs do not by themselves confirm suitability for exposed outdoor locations or wet environments.

How does the SMU02M-05 compare with the other SMU02M options?

The SMU02M-05 is rated at 2W with 5V output and 400A output current. The SMU02M-12 is 2W, 12V, and 167A, while the SMU02M-15 is 2W, 15V, and 133A, so the series varies by output voltage and output current within the same 2W platform.

Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Mean Well

Mean Well SMU02M-05 DC-DC Converter - 2W - 10.8~13.2V in 5V out 400mA

SKU:

SMU02M-05

Log in to see price Trade pricing & online ordering for account holders

Notify me when it's back in stock

The SMU02M is a 2W Mean Well power converter (input range: 4.5~5.5V, operating temperature: -40~+85℃).

Key Features

✓ Input voltage range: 4.5~5.5V
✓ 1.5KVDC reinforced I/O isolation
✓ Wide operating temperature: -40~+85℃
✓ Protections: Short circuit / Overload
✓ Safety approvals: WITHSTAND VOLTAGE ISOLATION RESISTANCE ℃ -55 ~ +125 ℃ ± , 10 ~ 95% RH ℃ ) (0 ~ 50 0.05% / 10 ~ 500Hz, 2G 10min./1 cycle, period for 60min. each along X, Y, Z axes EAC TP TC 004
✓ 3 years warranty

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Model	Power	Voltage	Current	IP Rating
Mean Well SMU02N-15 DC-DC Converter - 2W - 21.6~26.4V in 15V out 133mA	2W	15V	0.13A	Indoor	View
Mean Well SMU02N-12 DC-DC Converter - 2W - 21.6~26.4V in 12V out 167mA	2W	12V	0.16A	Indoor	View
Mean Well SMU02N-05 DC-DC Converter - 2W - 21.6~26.4V in 5V out 400mA	2W	5V	0.4A	Indoor	View
Mean Well SMU02M-15 DC-DC Converter - 2W - 10.8~13.2V in 15V out 133mA	2W	15V	0.13A	Indoor	View
Mean Well SMU02M-12 DC-DC Converter - 2W - 10.8~13.2V in 12V out 167mA	2W	12V	0.16A	Indoor	View
Mean Well SMU02L-15 DC-DC Converter - 2W - 4.5~5.5V in 15V out 133mA	2W	15V	0.13A	Indoor	View
Mean Well SMU02L-12 DC-DC Converter - 2W - 4.5~5.5V in 12V out 167mA	2W	12V	0.16A	Indoor	View
Mean Well SMU02L-05 DC-DC Converter - 2W - 4.5~5.5V in 5V out 400mA	2W	5V	0.4A	Indoor	View
