Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Mean Well SMU02N-05 DC-DC Converter - 2W - 21.6~26.4V in 5V out 400mA

SKU:

SMU02N-05

Log in to see price Trade pricing & online ordering for account holders

Notify me when it's back in stock

The SMU02N is a 2W Mean Well power converter (input range: 4.5~5.5V, operating temperature: -40~+85℃).

Key Features

✓ Input voltage range: 4.5~5.5V
✓ 1.5KVDC reinforced I/O isolation
✓ Wide operating temperature: -40~+85℃
✓ Protections: Short circuit / Overload
✓ Safety approvals: WITHSTAND VOLTAGE ISOLATION RESISTANCE ℃ -55 ~ +125 ℃ ± , 10 ~ 95% RH ℃ ) (0 ~ 50 0.05% / 10 ~ 500Hz, 2G 10min./1 cycle, period for 60min. each along X, Y, Z axes EAC TP TC 004
✓ 3 years warranty

Frequently Asked Questions

Can I use the SMU02N-05 in a 24V control panel to power 5V logic boards?

It is intended for systems with a 21-26VAC input and provides a 5V constant voltage output. With a 2W rating and 400A listed output current, it fits low-power 5V control, embedded, or automation logic loads rather than higher-power devices.

Is the SMU02N-05 suitable for small embedded controllers or sensor interface circuits?

Yes, this model is aimed at low-power 5V electronics that need to run from a 21-26VAC source. The 2W output makes it a fit for compact embedded controller sections, interface boards, and similar low-demand industrial electronics.

Can this converter be used for 5V industrial monitoring or communication subcircuits?

It can be used where the end device needs a regulated 5V constant voltage supply and the available source is 21-26VAC. Because the unit is rated at 2W, it is better matched to monitoring, communications, and auxiliary logic functions than to larger 5V loads.

Is the SMU02N-05 appropriate for outdoor or harsh-temperature equipment?

The operating temperature range is -40°C to +85°C, which supports use across a wide temperature span. No IP rating is listed, so it is better suited to protected indoor enclosures rather than exposed outdoor or washdown locations.

How does the SMU02N-05 compare with the other SMU02N 2W versions?

Within the listed siblings, the SMU02N-05 is 2W with 5V output and 400A listed output current, while the SMU02N-12 is 2W with 12V output and 167A listed output current and the SMU02N-15 is 2W with 15V output and 133A listed output current. The main selection difference in this sibling group is the output voltage and listed output current, while all three are 2W models.

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Model	Power	Voltage	Current	IP Rating
Mean Well SMU02N-15 DC-DC Converter - 2W - 21.6~26.4V in 15V out 133mA	2W	15V	0.13A	Indoor	View
Mean Well SMU02N-12 DC-DC Converter - 2W - 21.6~26.4V in 12V out 167mA	2W	12V	0.16A	Indoor	View
Mean Well SMU02M-15 DC-DC Converter - 2W - 10.8~13.2V in 15V out 133mA	2W	15V	0.13A	Indoor	View
Mean Well SMU02M-12 DC-DC Converter - 2W - 10.8~13.2V in 12V out 167mA	2W	12V	0.16A	Indoor	View
Mean Well SMU02M-05 DC-DC Converter - 2W - 10.8~13.2V in 5V out 400mA	2W	5V	0.4A	Indoor	View
Mean Well SMU02L-15 DC-DC Converter - 2W - 4.5~5.5V in 15V out 133mA	2W	15V	0.13A	Indoor	View
Mean Well SMU02L-12 DC-DC Converter - 2W - 4.5~5.5V in 12V out 167mA	2W	12V	0.16A	Indoor	View
Mean Well SMU02L-05 DC-DC Converter - 2W - 4.5~5.5V in 5V out 400mA	2W	5V	0.4A	Indoor	View
