Can I use the SMU02N-12 in a 24V automation panel for 12V control electronics?

It is designed for a 21-26VAC input and provides a 12V constant voltage output. With a 2W rating and 167A listed output current, it is best suited to low-power 12V control and embedded electronics inside industrial equipment.

Is the SMU02N-12 a fit for 12V sensor modules or small automation accessories?

Yes, it fits low-power 12V loads that need to be derived from a 21-26VAC source. The 2W power level makes it more appropriate for auxiliary automation circuits and sensor-related electronics than for larger 12V devices.

Can this model power compact 12V embedded or relay-related circuits?

It can support compact 12V subcircuits where constant voltage output is required and the source falls within 21-26VAC. The small 11.6 × 10.14 × 7.5 mm package also supports dense electronics layouts where space is limited.

Is the SMU02N-12 suitable for indoor or outdoor use?

The operating range is -40°C to +85°C, so the temperature capability is broad for industrial electronics. No IP rating is listed, which means it is better treated as a part for protected indoor equipment rather than direct outdoor exposure.

How does the SMU02N-12 differ from the other 2W SMU02N options?

The sibling models listed are SMU02N-05 at 2W, 5V, and 400A listed output current, SMU02N-12 at 2W, 12V, and 167A listed output current, and SMU02N-15 at 2W, 15V, and 133A listed output current. If you are choosing within this group, the decision is primarily the required output voltage and the corresponding listed output current.

Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Mean Well

Mean Well SMU02N-12 DC-DC Converter - 2W - 21.6~26.4V in 12V out 167mA

SKU SMU02N-12

Log in to see price Trade pricing & online ordering for account holders

Notify me when it's back in stock

The SMU02N is a 2W Mean Well power converter (input range: 4.5~5.5V, operating temperature: -40~+85℃).

Key Features

✓ Input voltage range: 4.5~5.5V
✓ 1.5KVDC reinforced I/O isolation
✓ Wide operating temperature: -40~+85℃
✓ Protections: Short circuit / Overload
✓ Safety approvals: WITHSTAND VOLTAGE ISOLATION RESISTANCE ℃ -55 ~ +125 ℃ ± , 10 ~ 95% RH ℃ ) (0 ~ 50 0.05% / 10 ~ 500Hz, 2G 10min./1 cycle, period for 60min. each along X, Y, Z axes EAC TP TC 004
✓ 3 years warranty

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Model	Power	Voltage	Current	IP Rating
Mean Well SMU02N-15 DC-DC Converter - 2W - 21.6~26.4V in 15V out 133mA	2W	15V	0.13A	Indoor	View
Mean Well SMU02N-05 DC-DC Converter - 2W - 21.6~26.4V in 5V out 400mA	2W	5V	0.4A	Indoor	View
Mean Well SMU02M-15 DC-DC Converter - 2W - 10.8~13.2V in 15V out 133mA	2W	15V	0.13A	Indoor	View
Mean Well SMU02M-12 DC-DC Converter - 2W - 10.8~13.2V in 12V out 167mA	2W	12V	0.16A	Indoor	View
Mean Well SMU02M-05 DC-DC Converter - 2W - 10.8~13.2V in 5V out 400mA	2W	5V	0.4A	Indoor	View
Mean Well SMU02L-15 DC-DC Converter - 2W - 4.5~5.5V in 15V out 133mA	2W	15V	0.13A	Indoor	View
Mean Well SMU02L-12 DC-DC Converter - 2W - 4.5~5.5V in 12V out 167mA	2W	12V	0.16A	Indoor	View
Mean Well SMU02L-05 DC-DC Converter - 2W - 4.5~5.5V in 5V out 400mA	2W	5V	0.4A	Indoor	View
