AcTec ET-105-12 Electronic Transformer — 105W 12VAC 9.1A Triac Dimmable

constant voltage AC, CE/RCM/CB certified, 198–264VAC input, triac dimmable, 5-year warranty

SKU:

ET-105-12

Notify me when it's back in stock

Description

The AcTec ET-105-12 is a 105W dimmable electronic transformer delivering a stable 12VAC output, designed for halogen lamps, LED lamps, and other low-voltage AC devices including electric towel rails. Supporting both leading-edge and trailing-edge (triac) dimming, it delivers smooth flicker-free control at up to 9.1A with 95% full-load efficiency, carrying CE, RCM, and CB certifications.

Accepting 198–264VAC input at 50/60Hz, the ET-105-12 is fully compatible with NZ/AU supply conditions. It features galvanic isolation, built-in short-circuit, overload, and over-temperature protection with auto-recovery, and a minimum load of 0W supporting up to 8 LED lamps simultaneously. The independent screwless enclosure with captured terminal screws simplifies installation.

Key Features

✓Dimmable: leading-edge and trailing-edge (triac) compatible
✓12VAC output at up to 9.1A (105W max)
✓High efficiency: up to 95% at full load
✓AC input: 198–264VAC, 50/60Hz
✓Built-in protections: short-circuit, overload, over-temperature (auto-recover)
✓Galvanic isolation between primary and secondary
✓Zero minimum load — supports up to 8 LED lamps simultaneously
✓Compact independent enclosure: 120 × 45 × 28mm, 112g

Specifications

Brand

AcTEC
Standards Met

CB,CE,RCM
Operation Mode

Constant Voltage
Length

12 cm
Width

4.5 cm
Height

2.8 cm
Weight

0.11 kg

File Downloads

::specification::

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Model	Power	Voltage	Current	IP Rating
AcTec ET-105-24 Electronic Transformer — 105W 24VAC 4.6A Triac Dimmable	—	—	—	IP20	View
