Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Archilight Dot Mini 22 Track Light 3W - White + Gold

SKU KC-10.001A01-16D-3000K-WG

Log in to see price Trade pricing & online ordering for account holders

Configure — 5 variants

KC-10.001A01-16D-3000K-WG

LED Colour

Beam Angle

5 matching

Pick options to narrow the list, or tap a row to select. Dimmed chips have no matching combination.

Product variants

Available to order

Technical drawings

Archilight Dot Mini 22 Track Light 3W - White + Gold XS TRACK Mini A surface — XS TRACK Mini A surface

Archilight Dot Mini 22 Track Light 3W - White + Gold XS TRACK Mini A surface (2) — XS TRACK Mini A surface (2)

Archilight Dot Mini 22 Track Light 3W - White + Gold XS TRACK Mini A surface (3) — XS TRACK Mini A surface (3)

Archilight Dot Mini 22 Track Light 3W - White + Gold XS TRACK Mini O suspended — XS TRACK Mini O suspended

Archilight Dot Mini 22 Track Light 3W - White + Gold XS TRACK Mini O suspended (2) — XS TRACK Mini O suspended (2)

Archilight Dot Mini 22 Track Light 3W - White + Gold CURVED TRACK Mini AC — CURVED TRACK Mini AC

Archilight Dot Mini 22 Track Light 3W - White + Gold CURVED TRACK Mini AC (2) — CURVED TRACK Mini AC (2)

Archilight Dot Mini 22 Track Light 3W - White + Gold XS TRACK Mini A / Mini O / Mini T — XS TRACK Mini A / Mini O / Mini T

Downloads

Datasheet1

Archilight Dot Mini 22 Track Light 3W - White + Gold datasheetdot_22_spec_sheet.pdf PDF Download

FAQ

What type of product is the Archilight Dot Mini 22 Track Light 3W?

The Archilight Dot Mini 22 is a compact LED track light module designed for Archilight mini track lighting systems. It uses a minimalist ultra-thin form factor to keep attention on the light effect rather than the fitting itself.

What track systems is this light designed to pair with?

This parent model is intended to pair with Archilight Mini-series track systems. The product description specifically lists Mini S Surface Tracks, Mini T Trimless Tracks, and Mini O Suspended Tracks as matching options.

What variant options are available in this parent product family?

Across this parent family, buyers can choose from beam angles of 16, 29, or 34 degrees. Available colour temperature options shown in the variant data are 3000K and 4000K, with additional variants also listed as 2700-6000K.

What are the main performance specifications of this track light?

This model is rated at 3W and delivers 216 lumens in the listed child variants. It also has CRI 90, a 50,000-hour lifetime, and a 5-year warranty, making it suitable for projects that need consistent light quality and long service life.

Is a driver included with the Archilight Dot Mini 22 Track Light?

No, the product data states that the driver is not included. The light is specified for 48V power input, so buyers should confirm system compatibility when selecting supporting components.

Is this track light dimmable?

No, the listed dimming control for this parent model is none. This means the variants in this family should be treated as non-dimmable based on the provided data.

What size is the Archilight Dot Mini 22 Track Light 3W?

The parent model dimensions are 100 mm in length, 22 mm in width, and 48 mm in height. Its compact size supports the Mini-series design goal of creating a clean, visually discreet lighting effect.

Where is this light best suited to be used?

This product is best suited to dedicated interior spaces where a small, refined luminaire is preferred and the lighting effect should remain the visual focus. Its minimalist Mini-series design makes it appropriate for architectural and decorative track lighting applications.

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Model	Power	CRI	Dimming	UGR
Archilight Dot Mini 22 Track Light 3W - White	3W	90	Non Dimmable	19	View
Archilight Dot Mini 22 Track Light 3W - Black + Gold	3W	90	Non Dimmable	19	View
Archilight Dot Mini 22 Track Light 3W - Black	3W	90	Non Dimmable	19	View
