Over 15 years experience of providing support of MEAN WELL Power Supplies
ENVO ENC-18-500 Dimmable LED Driver 9W-18W 500mA Constant Current
Log in to see priceOverview
Features
- Dimmable (AC Phase Cut)
- Large screw terminal connection
- Low Cost, High Reliability
- Isolation class II
- Cooling by free air convection
- Protections: Short Circuit / Over Temperature
- 2 years warranty
Specifications
500mA Models
- SKU
- ENC-18-500
- Wattage
- 18W
- Current
- 500mA
- Min. Load
- 9W
- Dimension(mm)
- 129 x 44 x 28
Certifications & ratings
- Certification marks
- CE, RoHS
Downloads
Datasheet1
FAQ
What type of LED driver is the ENVO ENC-18-500?
The ENVO ENC-18-500 is a constant current LED driver rated at 500mA. It is designed for LED loads within a 9W to 18W range and is sold as a dimmable model in the ENC series.
Is the ENVO ENC-18-500 dimmable?
Yes. This model supports AC phase cut dimming, which makes it suitable for applications where phase cut dimming is required. The product description specifically identifies it as a dimmable constant current driver.
What kinds of applications is the ENC-18-500 best suited for?
This model is generally suited to constant current LED lighting applications that need a 500mA driver and up to 18W output. It is positioned as a low cost, high reliability option, which makes it relevant for commercial or trade buyers looking for dependable LED driver supply.
What protections are included on the ENVO ENC-18-500?
The product description states that this driver includes short circuit protection and over temperature protection. Those built-in protections support safer operation in normal LED driver use cases.
What operating temperature range does the ENC-18-500 support?
The stated operating temperature range is -20 degrees C to 55 degrees C. That gives it a usable range for many indoor and protected lighting environments where temperature conditions stay within those limits.
What warranty is offered with the ENVO ENC-18-500?
ENVO provides a 2-year warranty for this model. That warranty period is stated directly in the product information provided for the ENC series.
