ENVO ENC-18-500 Dimmable LED Driver 9W-18W 500mA Constant Current
Please Login for Pricing
Description
Description
ENC Series is a low cost, high reliability constant current driver.
It is dimmable(AC Phase Cut) and it has large screw for easy connection and it also has short circuit and over temperature protection.
We provide two years waranty on those products
Specifications
Specifications
-
BrandEnvo
-
SeriesSC Envo Series
-
Power Rating18 Watt
-
Output Voltage18 Volt
-
Rated Current0.5 Ampere
-
Input Voltage200V~250V
-
Standards MetCB,CE,ROHS,SAA
-
Operation ModeConstant Current
-
Operating Temperature-20°C~55°C
-
Warranty2 Year
-
Length12.9 cm
-
Width4.4 cm
-
Height2.8 cm
-
Weight0.3 kg
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
What type of LED driver is the ENVO ENC-18-500?
The ENVO ENC-18-500 is a constant current LED driver rated at 500mA. It is designed for LED loads within a 9W to 18W range and is sold as a dimmable model in the ENC series.
Is the ENVO ENC-18-500 dimmable?
Yes. This model supports AC phase cut dimming, which makes it suitable for applications where phase cut dimming is required. The product description specifically identifies it as a dimmable constant current driver.
What kinds of applications is the ENC-18-500 best suited for?
This model is generally suited to constant current LED lighting applications that need a 500mA driver and up to 18W output. It is positioned as a low cost, high reliability option, which makes it relevant for commercial or trade buyers looking for dependable LED driver supply.
What protections are included on the ENVO ENC-18-500?
The product description states that this driver includes short circuit protection and over temperature protection. Those built-in protections support safer operation in normal LED driver use cases.
What operating temperature range does the ENC-18-500 support?
The stated operating temperature range is -20 degrees C to 55 degrees C. That gives it a usable range for many indoor and protected lighting environments where temperature conditions stay within those limits.
What warranty is offered with the ENVO ENC-18-500?
ENVO provides a 2-year warranty for this model. That warranty period is stated directly in the product information provided for the ENC series.
