Envo SC-45-12PWM 45W 12V Power Supply - PWM Dimmable LED Driver

Overview

SC-45-12PWM is the 12V output model of this series: rated current 0 - 3.75A, rated power 45W, typical efficiency 81%.

Features

Output constant voltage
Universal AC input:100-265VAC
Built-in active PFC function
High efficiency up to 86%
Protections:Short circuit/Over current/Over loading
Cooling by free air convection
Fully isolated plastic case with terminals IP20
Class 2 power unit
Three in one dimming function(0/1-10Vdc or PWM signal or resistance)
Dimming range: 0-100%
Suitable for LED lighting and moving sign applications
Compliance to worldwide safety regulations for lighting
Three years warranty

Specifications

SC-45-12PWMSpecifications from the official datasheetDownload datasheet PDF

Output

DC Voltage: 12V
Voltage Tolerance: ±0.5V
Rated current: 0 - 3.75A
Rated power: 45W

Input

Voltage Range: 100-265VAC
Frequency Range: 47-63Hz
Power Factor: PF≥0.95/120VAC PF≥0.90/230VAC PF≥0.90/265VAC（Full loading）
Efficiency（Typ.）: 81%
AC Current（Max.）: 0.51A
Leakage current: ＜0.5mA

Protection

Short Circuit: Hiccup mode, recovers automatically after fault condition is removed
Over Loading: ≤120%
Over Current: ≤1.2*Iout

Environment

Working TEMP.: -40~+60℃
Working Humidity: 20-90%RH non-condensing
Storage TEMP.,Humidity: -40~+80℃, 10-95%RH
TEMP.coefficient: ±0.03%/℃ (0~50℃)
Vibration: 10-500Hz, 2G 12min./1 cycle, period for 72min. each along X,Y,Z axes

Safety&EMC

Safety standards: EN61347-1 EN61347-2-13
Withstand voltage: I/P-O/P:3.75KVAC
Isolation resistance: I/P-O/P I/P-FG O/P-FG: 100M Ohms/500VDC/25℃/70%RH
EMC EMISSION: Compliance to EN55015,EN61000-3-2 (≥60%load)
EMC IMMUNITY: Compliance to EN61000-4-2,3,4,5,6,11, EN61547, light industry Level Criteria A

Others

Net.Weight: 0.55Kg
Size: 180*60*35mm (L*W*H)
Packing: 355*215*215mm 20PCS

Test conditions and notes3

1. All parameters NOT specially mentioned are measured at 230VAC input , rated load and 25℃ of ambient temperature.
2. Tolerance:includes set up tolerance,line regulation and load regulation .
3. The power supply is considered as a component that will be operated in combination with final Equipment. Since EMC performance will be affected by the complete installation,the final equipment manufactures must be-qualify EMC Directive on the complete installation again.

Technical drawings

SC-45-12PWM 45W 0-10V dimmable driver Mechanical Specification — 45W 0-10V dimmable driver Mechanical Specification

SC-45-12PWM Dimming Curve — Dimming Curve

SC-45-12PWM Derating Curve — Derating Curve

SC-45-12PWM Connect Drawing — Connect Drawing

Downloads

Datasheet1

SC-45-12PWM datasheetsc_45_12_24pwm.pdf PDF Download

FAQ

What are the main output specifications of the Envo SC-45-12PWM?

The Envo SC-45-12PWM is a 45W constant-voltage power supply with a 12V DC output. Its rated output current is 3.75A, making it suitable for 12V LED applications that fit within that power capacity.

Is the SC-45-12PWM dimmable?

Yes. This model is described as PWM dimmable and the product description also lists a three-in-one dimming function using 0/1-10V DC, PWM signal, or resistance, with a 0-100% dimming range.

What kinds of applications is this power supply designed for?

This model is intended for LED lighting and moving sign applications. Because it is a 12V constant-voltage unit, it is best matched to products that require a 12V constant-voltage power source rather than constant-current output.

Can this power supply handle a wide AC input range?

Yes. The SC-45-12PWM has a universal AC input range of 100-265VAC, which gives it flexibility across different mains supply environments. It also includes active PFC and is rated for up to 86% efficiency.

Is the SC-45-12PWM suitable for exposed outdoor locations?

No. The SC-45-12PWM has an IP20 plastic case, so it is not intended for direct exposure to water or dust. It is generally better suited to protected indoor environments or enclosed applications where the power supply is shielded from the elements.

What operating temperature range does this model support?

The listed operating temperature range is -40°C to 60°C. That makes it suitable for demanding environments, provided the application stays within the product's specified limits.
