Lifud LF-GOE100YV024A LED Driver 100.08W 24V - Flicker Free 4.17A
Please Login for Pricing
Description
Description
LF-GOE100YV024A series is a 100W LED power supply with a built-in potentiometer. Rated input voltage 100-277VAC. Input voltage limit 90-305VAC. This product was specifically designed for outdoor lighting, high bay light, flood light, lighting project. Super high efficiency and excellent heat-dissipation properties of GOE help to extend the product lifetime. The high-power-factor GOE makes better use of the power grid. Its low harmonic interference means low interference with the power grid and the electric devices in the circuit. All-round protection design improves the product stability which helps to save users’ maintenance cost. The potentiometer at the bottom helps to adjust the output voltage/power of the product, satisfying customers’ various demands.
Features
- Conversion efficiency: up to 91%
- Input voltage: 100-277Vac
- THD<15%
- Output voltage adjustable via a potentiometer; It helps to simplify your inventory management
- Surge protection: L-N: 6KV; L/N-GND: 8KV
- All-round protection: over temperature protection
- over voltage protection
- short circuit protection & IP67
- Flicker free output
- percent flicker ≤0.5%
Applications
- Outdoor lighting
- LED flood light
- Lighting project
Specifications
Specifications
-
BrandLifud
-
SeriesGOE Series
-
Power Rating100.08 Watt
-
Output Voltage24 Volt
-
Rated Current4.17 Ampere
-
Input Voltage100V~277V
-
Standards MetCB,CE,ENEC,FCC,RCM,SAA,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~60°C
-
Warranty5 Year
-
Length17 cm
-
Width6.1 cm
-
Height3.4 cm
-
Weight0.7 kg
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
What type of LED driver is the Lifud LF-GOE100YV024A?
The LF-GOE100YV024A is a 24V constant-voltage LED driver rated at 100.08W. It is designed for applications that need stable 24V output with flicker-free performance.
What applications is the LF-GOE100YV024A designed for?
This model is intended for outdoor lighting, LED flood lights, high bay lights, and general lighting projects. Its IP67 rating, surge protection, and wide operating temperature range make it suited to demanding commercial and industrial environments.
Is the LF-GOE100YV024A suitable for outdoor environments?
Yes. Lifud specifies this driver for outdoor lighting, and it carries an IP67 rating for protection against harsh environmental exposure. It also operates from -40°C to 60°C, which supports use in a wide range of climates.
Does this LED driver provide flicker-free output?
Yes, the LF-GOE100YV024A is described as flicker free. The listed percent flicker is 0.5% or less, which makes it a strong choice for lighting projects where output quality matters.
Can the output be adjusted on this model?
Yes. This driver includes a built-in potentiometer that allows the output voltage or power to be adjusted within the product's design range. That can be useful for projects that need some flexibility while staying within a 24V driver platform.
What input power range does the LF-GOE100YV024A support?
The rated input voltage is 100-277VAC, with an input limit range of 90-305VAC. This wide input range makes it practical for commercial projects where supply conditions may vary.
What protections and reliability features does this model include?
The LF-GOE100YV024A includes over-temperature protection, over-voltage protection, short-circuit protection, and surge protection rated at 6KV line-to-neutral and 8KV line/neutral-to-ground. Lifud also backs this model with a 5-year warranty.
