Lifud LF-GOE200YV024A LED Driver 200.16W 24V - Flicker Free


|

Description

LF-GOE200YV024A series is a 200W LED power supply with a built-in potentiometer. Rated input voltage 100-277VAC. Input voltage limit 90-305VAC. This product was specifically designed for outdoor lighting, high bay light, flood light, lighting project. Super high efficiency and excellent heat-dissipation properties of GOE help to extend the product lifetime. The high-power-factor GOE makes better use of the power grid. Its low harmonic interference means low interference with the power grid and the electric devices in the circuit. All-round protection design improves the product stability which helps to save users’ maintenance cost. The potentiometer at the bottom helps to adjust the output voltage/power of the product, satisfying customers’ various demands.

Features

  • Conversion efficiency: up to 93%
  • Input voltage: 100-277Vac
  • THD<15%
  • Output voltage adjustable via a potentiometer; It helps to simplify your inventory management
  • Surge protection: L-N: 6KV; L/N-GND: 8KV
  • All-round protection: over temperature protection
  • over voltage protection
  • short circuit protection & IP67
  • Flicker free output
  • percent flicker ≤0.5%

Applications

  • Outdoor lighting
  • LED flood light
  • Lighting project

Specifications

  • Brand
    Lifud
  • Series
    GOE Series
  • Power Rating
    200.16 Watt
  • Output Voltage
    24 Volt
  • Rated Current
    8.34 Ampere
  • Input Voltage
    100V~277V
  • Standards Met
    CB,CE,ENEC,FCC,RCM,SAA,UL
  • Operation Mode
    Constant Voltage
  • Operating Temperature
    -40°C~60°C
  • Warranty
    5 Year
  • Length
    22.8 cm
  • Width
    6.3 cm
  • Height
    3.4 cm
  • Weight
    0.92 kg

File Downloads
