Mean Well A301-1K0-F5 Modified sine wave 1000W 230V - DC-AC Inverter
Log in to see priceOverview
A301-1K0-F5 is the model of this series: rated power 1000W, typical efficiency 82%.
Features
- 12V or 24V DC input
- Power ON-OFF switch
- Input voltage range: -15% ~ +25%
- Output voltage regulation:±10%
- Protections: Bat. Low alarm/Bat. Low shutdown/Over voltage/ Over temp./Output short/Input polarity reverse/Over load.
- Output waveform: Modified sine wave
- Cooling fan ON-OFF control
- ON/OFF remote control(Optional/Order No.: RC-1700)
- Approvals: E13/ EAC / CE / UKCA
- 1 year warranty
Specifications
OUTPUT
- SAFETY MODEL NO.
- A301-1K0
- AC VOLTAGE
- 230V
- RATED POWER
- 1000W
- PEAK POWER
- 1200W<30min.
- SURGE POWER
- 2400W
- WAVEFORM
- Modified Sine Wave
- FREQUENCY
- 50Hz±1%
- AC REGULATION
- ±10%
- STANDARD RECEPTACLES
- TYPE-5 (Australia)
- LED INDICATOR
- Green LED for power on; Yellow LED for O.T.P.; Red LED for power failure status
INPUT
- DC CURRENT
- 110A
- NO LOAD CURRENT DRAW
- 0.4A
- DC VOLTAGE
- 12V
- VOLTAGE RANGE
- 10 ~ 15VDC
- EFFICIENCY (Typ.)
- 82%
- DC CONNECTOR
- 1000mm R type terminal
- FUSE
- 30A*5
PROTECTION
- BAT. LOW ALARM
- 10±0.5V
- BAT. LOW SHUTDOWN
- 9.5±0.5V
- OVER LOAD
- >1200W shut down o/p voltage, re-power to recover
- OVER VOLTAGE
- 15 ~ 16V
- OVER TEMPERATURE
- 60±5℃/ 140±9oF
- OUTPUT SHORT
- Shut-off
- BAT. POLARITY
- By fuse open
ENVIRONMENT
- WORKING TEMP.
- 0 ~ 30℃@ 100% load, 40℃@ 70% load
- WORKING HUMIDITY
- 20% ~ 90% RH non-condensing
- STORAGE TEMP., HUMIDITY
- -30 ~ +70℃ / -22 ~ +158oF, 10 ~ 95% RH
- TEMP. COEFFICIENT
- ±0.05% / ℃ (0 ~ 50℃)
SAFETY & EMC
- SAFETY STANDARDS
- EAC TP TC 004 approved
- ISOLATION RESISTANCE
- I/P-O/P:100M Ohms / 500VDC / 25℃/ 70% RH
- EMI RADIATION
- Compliance to BS EN/EN55014-1, EAC TP TC 020
- EMS IMMUNITY
- Compliance to BS EN/EN55014-2, IEC61000-4-2,3, EAC TP TC 020
- LVD
- Compliance to BS EN/EN62368-1
OTHERS
- MTBF
- 98Khrs min. MIL-HDBK-217F (25℃)
- DIMENSION
- 310*210*85mm (L*W*H)
- PACKING
- 3.3kg ; 4pcs / 17.5kg / CARTON
- COOLING
- >40℃ (NTC) fan on
- APPLICATIONS
- Home appliance, Power tools, Office and Portable equipment and Vehicle ...etc.
Technical drawings
Downloads
FAQ
What is the Mean Well A301-1K0-F5 used for?
The A301-1K0-F5 is a 1000W DC-AC inverter designed for applications that need 230V AC output from a 12V DC power source. It suits home appliances, power tools, office and portable equipment, and vehicle use where modified sine wave output is acceptable.
Does this inverter produce pure sine wave output?
No. The A301-1K0-F5 produces a modified sine wave output, which is different from a pure sine wave inverter. Buyers comparing models should confirm that their equipment is compatible with modified sine wave power before choosing this unit.
What input voltage options does the A301-1K0-F5 support?
The A301-1K0-F5 is the 12V DC input version of the A301/302-1K0 series, with an input voltage range of 10 to 15VDC. The 24V DC input version of the series is the A302 model.
What protection features are included in this inverter?
The A301-1K0-F5 includes battery low alarm, battery low shutdown, over voltage, overload, over temperature, output short circuit, and input reverse polarity protection (by fuse open). Output short protection is described as shut-off in the product specification.
What operating temperature range is specified for this model?
The specified working temperature is 0 to 30°C at 100% load, and up to 40°C at 70% load. This means output capacity is reduced at higher ambient temperatures, so environment and load level both matter in real-world use.
Does the A301-1K0-F5 support remote operation?
Yes. The spec sheet shows an ON/OFF remote control, available separately as Order No. RC-1700. The cooling fan is NTC-controlled and switches on above 40°C.
