Can I use the DKM10A-05 in a 12V embedded system that needs a 5V rail?

Yes, the 9-18V input range matches 12V-class systems and the unit provides 5V constant-voltage output. It is suitable for low-power embedded electronics as long as the load stays within 10W and 1A.

Is the DKM10A-05 a fit for sensor, logic, or controller boards in industrial equipment?

It is a practical option for low-power boards that run on 5V and are fed from a 9-18V source. The 10W rating and 1A output make it better suited to compact control electronics than to heavier 5V loads.

Can this converter power a 5V communications or interface module inside automation hardware?

Yes, it can support 5V constant-voltage interface electronics when the upstream supply is within 9-18V. Its 25.4 × 25.4 × 10.2 mm footprint also makes it suitable for dense embedded assemblies with limited board space.

How does the DKM10A-05 compare with the DKM10A-12 and DKM10A-15?

All three are 10W models with a 9-18V input range, but the outputs are different. The DKM10A-05 is 5V at 1A, the DKM10A-12 is 12V at 416A, and the DKM10A-15 is 15V at 333A.

Can the DKM10A-05 be used in outdoor equipment or wide-temperature enclosures?

Its operating range is -40°C to +85°C, which supports demanding temperature conditions inside equipment. No IP rating is listed, so the specs do not support direct exposed outdoor use without additional enclosure protection.

Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Mean Well

Mean Well DKM10A-05 DC-DC Converter - 10W - 9~18V in ±5V out 1A

SKU:

DKM10A-05

Log in to see price Trade pricing & online ordering for account holders

Notify me when it's back in stock

SKM10 and DKM10 series are 10W isolated and regulated module type DC-DC converter with DIP 1"x1" package. It features international standard pins, a high efficiency up to 90%, wide working temperature range -40~+85℃, 1.5KVDC I/P-O/P isolation voltage, Compliance to EN55032 radiated Class A without additional components, continuous-mode short circuit protection, etc. The models account for different input voltage 4.7~9V, 9~18V, 18~36V and 36~75V 2:1 wide input range, and various output voltage, 3.3V/5V/12V/15V for single output and ±5V/±12V/±15V for dual outputs, which are suitable for all kinds of systems, such as industrial control, telecommunication field, distributed power architecture, and so on.

Key Features

✓✓✓DIP 1"x1" package with industry standard pinout
✓✓✓2:1 wide input range
✓✓✓Operating temperature range -40 ~ +85℃
✓✓✓No minimum load required
✓✓✓Comply to EN55032 radiated Class A without additional components
✓✓✓High efficiency up to 90%
✓✓✓Protections: Short circuit (Continuous} / Overload / Over voltage / Input under voltage
✓✓✓1.5KVDC I/O isolation
✓✓✓Remote ON/OFF control and Triming output (±10%)
✓✓✓3 years warranty

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Model	Power	Voltage	Current	IP Rating
Mean Well DKM10W8-15 10W DC-DC Converter ±15VDC 330mA	—	—	—	Indoor	View
Mean Well DKM10W8-12 10W DC-DC Converter ±12VDC 420mA	—	—	—	Indoor	View
Mean Well DKM10E-15 DC-DC Converter - 10W - 4.7~9V in ±15V out 333mA	10W	15V	0.33A	Indoor	View
Mean Well DKM10E-12 DC-DC Converter - 10W - 4.7~9V in ±12V out 416mA	10W	12V	0.41A	Indoor	View
Mean Well DKM10E-05 DC-DC Converter - 10W - 4.7~9V in ±5V out 1A	10W	5V	1A	Indoor	View
Mean Well DKM10C-15 DC-DC Converter - 10W - 36~75V in ±15V out 333mA	10W	15V	0.33A	Indoor	View
Mean Well DKM10C-12 DC-DC Converter - 10W - 36~75V in ±12V out 416mA	10W	12V	0.41A	Indoor	View
Mean Well DKM10C-05 DC-DC Converter - 10W - 36~75V in ±5V out 1A	10W	5V	1A	Indoor	View
Mean Well DKM10B-15 DC-DC Converter - 10W - 18~36V in ±15V out 333mA	10W	15V	0.33A	Indoor	View
Mean Well DKM10B-12 DC-DC Converter - 10W - 18~36V in ±12V out 416mA	10W	12V	0.41A	Indoor	View
Mean Well DKM10B-05 DC-DC Converter - 10W - 18~36V in ±5V out 1A	10W	5V	1A	Indoor	View
Mean Well DKM10A-15 DC-DC Converter - 10W - 9~18V in ±15V out 333mA	10W	15V	0.33A	Indoor	View
Mean Well DKM10A-12 DC-DC Converter - 10W - 9~18V in ±12V out 416mA	10W	12V	0.41A	Indoor	View
