Mean Well DR-RDN20 Redundancy Module Power Supply - DIN Rail
Please Login for Pricing
Description
Description
MEAN WELL DR-RDN20 series Power Supply Module are 20A Power Supply Redundancy module with high efficiency, long life, and high reliability.
Features
- Suitable for redundant operation of 24V system
- Installed on DIN Rail TS35 / 7.5 or 15
- Relay contact signal output and LED indicator for input failure alarm
- Cooling by free air convection
- 3 years warranty
Specifications
Specifications
-
BrandMean Well
-
SeriesDR-DRN20
-
Output Voltage12 Volt
-
Rated Current20 Ampere
-
Input Voltage21V~28V
-
Standards MetCE,cUL,EAC
-
Operating Temperature-40°C~85°C
-
Warranty3 Year
-
Length12.52 cm
-
Width10 cm
-
Height5.55 cm
-
Weight0.5 kg
