Mean Well

Mean Well ELGC-300-L-AB Power Supply 300W 1400mA - Adjustable and Dimmable

SKU ELGC-300-L-AB
Log in to see price Trade pricing & online ordering for account holders
Log in or apply for a trade account →

Select model — 28 in this family

ELGC-300-L-AB
Available to order
|

Overview

ELGC-300-L-AB is the model of this series: typical efficiency 94.5%. Type AB: Output constant power adjustable via built-in lo potentiometer + 3 in 1 dimming function (0~10Vdc, 10V PWM signal and resistance) (IP67).

ELGC-300 series is a 300W LED AC/DC driver featuring the constant power mode and high voltage output. ELGC-300 operates from 100~305VAC and offers models with different rated current ranging between 1300mA and 8000mA. Thanks to the high efficiency up to 94.5%, with the fanless design, the entire series is able to operate for -40℃~+85℃ case temperature under free air convection. The design of metal housing and IP67 ingress protection level allows this series to fit both indoor and outdoor applications. Moreover the innovative environment-adaptive capability allows this series to reliably light on the LEDs for all kinds of application environments in almost any spots that may install LED luminaires in the world. ELGC-300 is equipped with various function options, such as dimming methodologies, so as to provide the optimal design flexibility for LED lighting system.

Features

  • Full power at 65~100% operation(Constant Power )
  • Protection Functions: OCP,SCP,OVP,OTP
  • IP67 design for indoor or outdoor installations
  • Function options: output adjustable via potentiometer; 3 in 1 dimming (dim-to-off)
  • Typical lifetiem>50000 hours and 5 years warranty
  • Surge protection with 6KV/4KV
  • Latest safety requriirements of IEC61347/GB/T19510 and UL8750

Specifications

ELGC-300-L-ABSpecifications from the official datasheet (2026-07-06 edition)

OUTPUT

DEFAULT CURRENT
1400mA
RATED POWER (200 ~ 305VAC)
301W
RATED POWER (100 ~ 180VAC)
256W
CONSTANT CURRENT REGION
116 ~232V
FULL POWER CURRENT RANGE
1300~2000mA
OPEN CIRCUIT VOLTAGE (max.)
240V
CURRENT ADJ. RANGE (200 ~ 305VAC)
650~2000mA
CURRENT ADJ. RANGE (100 ~ 180VAC)
650~1700mA
CURRENT RIPPLE
5.0% max. @rated current
CURRENT TOLERANCE
±5%
SET UP TIMENote.9
500ms/230VAC, 500ms/115VAC

INPUT

VOLTAGE RANGENote.2
100 ~ 305VAC 142VDC ~ 431VDC (Please refer to "STATIC CHARACTERISTIC" ang “ DRIVING METHODS OF LED MODULE"section)
FREQUENCY RANGE
47 ~ 63Hz
POWER FACTOR (Typ.)
PF≧0.97 / 115VAC, PF≧0.95 / 230VAC, PF≧0.92 / 277VAC at full load (Please refer to "Power Factor Characteristic" section)
TOTAL HARMONIC DISTORTION
THD< 10% (@ load≧50% at 115VAC/230VAC ,@load≧75% at 277VAC) Please refer to “TOTAL HARMONIC DISTORTION (THD)” section
EFFICIENCY (Typ.)
94.5%
AC CURRENT (Typ.)
3A / 115VAC 1.6A / 230VAC 1.3A / 277VAC
INRUSH CURRENT(Typ.)
COLD START 45A(twidth=1200μs measured at 50% Ipeak) at 230VAC; Per NEMA 410
MAX. NO. of PSUs on 16A CIRCUIT BREAKER
2 unit(circuit breaker of type B) / 4 units(circuit breaker of type C) at 230VAC
LEAKAGE CURRENT
<0.75mA / 277VAC
STANDBY POWER CONSUMPTIONNote.5
Standby power consumption <0.5W for AB / ADA-Type(Dimming OFF)

PROTECTION

SHORT CIRCUIT
Constant current limiting, recovers automatically after fault condition is removed
OVER VOLTAGE
241 ~ 275V Shut down output voltage, re-power on to recovery
OVER TEMPERATURE
Tcase>85℃±5℃,derate power automatically by 6%/℃ max

ENVIRONMENT

WORKING TEMP.
Tcase=-40 ~ +85℃(Please refer to "OUTPUT LOAD vs TEMPERATURE" section)
MAX. CASE TEMP.
Tcase=+85℃
WORKING HUMIDITY
20 ~ 95% RH non-condensing
STORAGE TEMP., HUMIDITY
-40 ~ +80℃, 10 ~ 95% RH non-condensing
TEMP. COEFFICIENT
±0.03%/℃ (0 ~ 60℃)
VIBRATION
10 ~ 500Hz, 5G 12min./1cycle, period for 72min. each along X, Y, Z axes

SAFETY & EMC

SAFETY STANDARDS
UL8750(type”HL”), CSA C22.2 No. 250.13-12; ENEC BS EN/EN61347-1, BS EN/EN61347-2-13 independent, BS EN/EN62384; EAC TP TC 004;GB/T19510.1,GB/T19510.213; IP67;KC61347-1,KC61347-2-13 approved; Designed refer to AS/NZS 61347 & AS/NZS 60598
WITHSTAND VOLTAGE
I/P-O/P:3.75KVAC I/P-FG:2KVAC O/P-FG:1.5KVAC
ISOLATION RESISTANCE
I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25℃/ 70% RH
EMC EMISSION
Compliance to BS EN/EN55015, BS EN/EN61000-3-2 Class C (@ load≧50%); BS EN/EN61000-3-3;GB/T 17743,GB17625.1;KN15
EMC IMMUNITY
Compliance to BS EN/EN61000-4-2,3,4,5,6,8,11, BS EN/EN61547, light industry level (surge immunity Line-Earth 6KV, Line-Line 4KV);KN61547

OTHERS

MTBF
1637.5K hrs min. Telcordia SR-332 (Bellcore) ;170.1K hrs min. MIL-HDBK-217F (25℃)
LIFETIMENote.4
50000 hrs min.
DIMENSION
246*77*39.5mm (L*W*H)
PACKING
1.45Kg;9pcs/14Kg/0.76CUFT

MODEL ENCODING

Blank
Blank type available by modification; IP67
A
Output constant power adjustable via built-in lo potentiometer; IP67
AB (this model)
Output constant power adjustable via built-in lo potentiometer + 3 in 1 dimming function (0~10Vdc, 10V PWM signal and resistance); IP67
ADA
DALI-2 control technology with Io Adjustable via built-in Potentiometer; IP67
Test conditions and notes11
  1. 1. All parameters NOT specially mentioned are measured at 230VAC input, rated current and 25℃ of ambient temperature.
  2. 2. De-rating may be needed under low input voltages. Please refer to “STATIC CHARACTERISTIC” sections for details.
  3. 3. The driver is considered as a component that will be operated in combination with final equipment. Since EMC performance will be affected by the complete installation, the final equipment manufacturers must re-qualify EMC Directive on the complete installation again. (as available on https://www.meanwell.com//Upload/PDF/EMI_statement_en.pdf)
  4. 4. This series meets the typical life expectancy >50,000 hours of operation when Tcase, particularly tc point (or TMP, per DLC), is 70℃ or less.
  5. 5. To fulfill requirements of the latest ErP regulation for lighting fixture, this LED driver can only be used behind a switch without permanently connected to the mains.
  6. 6. Please refer to the warranty statement on MEAN WELL's website at http://www.meanwell.com
  7. 7. The ambient temperature derating of 3.5℃/1000m with fanless models and of 5℃/1000m with fan models for operating altitude higher than 2000m(6500ft).
  8. 8. For any application note and IP water proof function installation caution, please refer our user manual before using. https://www.meanwell.com/Upload/PDF/LED_EN.pdf
  9. 10. RCM is on a voluntary basis. Non IC classification Independent LED control gear is not suitable for residential installations.
  10. 11. Products sourced from the Americas regions may not have the ENEC/BIS/CCC/KC logo. Please contact your MEAN WELL sales for more information.
  11. 12. For A/AB/ADA type need to consider build in using to comply with Type HL application

Technical drawings

ELGC-300-L-AB BLOCK DIAGRAM
BLOCK DIAGRAM
ELGC-300-L-AB DRIVING METHODS OF LED MODULE
DRIVING METHODS OF LED MODULE
ELGC-300-L-AB DIMMING OPERATION
DIMMING OPERATION
ELGC-300-L-AB OUTPUT LOAD vs TEMPERATURE
OUTPUT LOAD vs TEMPERATURE
ELGC-300-L-AB STATIC CHARACTERISTIC
STATIC CHARACTERISTIC
ELGC-300-L-AB TOTAL HARMONIC DISTORTION
TOTAL HARMONIC DISTORTION
ELGC-300-L-AB MECHANICAL SPECIFICATION ※ AB-Type
MECHANICAL SPECIFICATION ※ AB-Type
ELGC-300-L-AB Recommend Mounting Direction
Recommend Mounting Direction

Typical applications

  • LED bay lighting
  • LED stage lighting
  • LED flood lighting
  • LED fishing lighting
  • LED horticulture lighting
  • Stadium lighting
  • Type “HL” for use in classⅠ,Division 2

Downloads

FAQ

Can I use the ELGC-300-L-AB for a high-voltage LED downlight array?

Yes, if the downlight requires 1400mA constant current and the LED load operates within the 116-232V CC range. Because this is a constant current driver, it should be matched to LED modules that specify current regulation rather than constant voltage input.

Is the ELGC-300-L-AB suitable for dimmable signage LED arrays?

It can be suitable when the signage array is a constant current load rated for 1400mA and falls within the 116-232V range. This version is adjustable and dimmable, which makes it a fit for applications that need output control with a constant current driver.

Can this driver power a small LED array with many LEDs in series?

Yes, if the array is designed for 1400mA constant current and its total forward voltage stays within 116V to 232V. The exact number of LEDs depends on each LED forward voltage, so the load must be evaluated by voltage range rather than a fixed LED count.

What should I match when selecting LEDs for the ELGC-300-L-AB?

Match the LED load to 1400mA constant current and a total forward voltage within the 116-232V constant current range. The number of LEDs depends on the forward voltage of each LED, which is why this driver should not be selected by LED count alone.

Is the ELGC-300-L-AB appropriate for outdoor conditions?

Yes, it has an IP67 waterproof rating, which is suitable for outdoor and wet environments. It is also rated for a working case temperature (Tcase) of -40°C to +85°C, supporting use in a wide temperature range.
