Mean Well ELGC-300-M-ADA Power Supply 300W 2800mA - Adjustable and DALI


|

Description

Features

Full power at 65~100% operation(Constant Power)
Protection Functions: OCP, SCP, OVP, OTP
IP67 design for indoor or outdoor installations
Function options: output adjustable via potentiometer; 3 in 1 dimming(dim-to-off); DALI-2 dimming
Typical lifetime>50000 hours and 5 years warranty
Surge protection with 6KV/4KV
Latest safety requirements of IEC61347/GB19510 and UL8750

General Specification

AC input voltage range 100~305VAC;142~431VDC
AC inrush current Cold start, 45A at 230VAC
DC adjustment range ±43% rated output current
Over voltage protection <146% rated output voltage
Setup time 500ms
Withstand voltage I/P-O/P: 3.75kVAC, I/P-FG: 2kVAC, O/P-FG: 1.5kVAC
Working temperature -40~+85°C
Safety standards UL8750 approved
EMC standards EN55015, EN61000-3-2 class C,EN61000-3-3, EN61000-4-2,3,4,5,6,8,11
Dimension (LxWxH) 246x77x39.5
Packing 9pcs / 14kg

Specifications

  • Brand
    Mean Well
  • Series
    ELGC-M Series
  • Power Rating
    301 Watt
  • Output Voltage
    120 Volt
  • Rated Current
    2.8 Ampere
  • Input Voltage
    100V~305V
  • Standards Met
    CB,CCC,CE,EAC,ENEC,KC,UL
  • Operation Mode
    Constant Current
  • Operating Temperature
    -40°C~85°C
  • Warranty
    5 Year
  • Length
    24.6 cm
  • Width
    7.7 cm
  • Height
    3.95 cm
  • Weight
    1.45 kg

File Downloads
