Description
Description
Features
3"x2" compact size |
120W convection, 150W peak (10sec) |
Built-in active PFC function |
EMI for both Class I & Class II configuration |
-30 + 85°C wide range operating temperature |
No-load power consumption<0.5W |
High efficiency up to 94% |
Protections: Short circuit/Overload/Over voltage/Over temperature |
Operating altitude up to 5000 meters (Note.5) |
3 years warranty |
General Specification
AC input voltage range | 80~264VAC; 113~370VDC |
AC inrush current | Cold start 30A/115VAC |
Leakage current | <0.75mA/240VAC |
Overload protection | 130 ~ 160% rated output power |
Over-voltage protection | 110%~130% rated output voltage |
Setup, rise, hold up time | 600ms, 30ms, 15ms |
Withstand voltage | I/P-O/P:3KVAC, I/P-FG:2KVAC, O/P-FG:0.5KVAC |
Working temperature | -30~+85°C |
Vibration | 10~500Hz, 2G 10min./1 cycle, the period for 60min. Each along X, Y, Z axes |
Safety standards | UL62368-1, TUV BS EN/EN62368-1, BS EN/EN60335-1, IEC62368-1, EAC TP TC 004 approved |
EMC standards | UL62368-1, TUV BS EN/EN62368-1, EAC TP TC 004 approved |
Connection | I/P: 3 Pin JST B3P-VH, O/P: 4 Pin JST B4P-VH |
Dimension (LxWxH) | 76.2x50.8x28 |
Packing | 100pcs / 14kg |
Specifications
Specifications
-
BrandMean Well
-
SeriesEPP Series
-
Power Rating114 Watt
-
Output Voltage15 Volt
-
Rated Current7.6 Ampere
-
Input Voltage80V~264V
-
Standards MetCB,CE,EAC,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-30°C~85°C
-
Warranty3 Year
-
Length7.62 cm
-
Width5.08 cm
-
Height2.8 cm
-
Weight0.13 kg
