Mean Well GSM12U05-P1J Power Supply 12W 5V


|

Description

Features

Universal AC input / Full range
Energy efficiency level VI
Medical safety approved (2 x MOPP)
Extremely low leakage current
No load power consumption < 0.075W(<0.1W for 18V/48V)
High efficiency up to 87%
Class II power (without earth pin)
Protections: Short circuit / Overload / Over voltage
Fully enclosed plastic case
100% full load burn-in test
3 years warranty

General Specification

AC input voltage range 80~264VAC ; 113~370VDC
AC inrush current (max.) Cold start, 60A at 230VAC
Overload protection 110%~140% rated output voltage, hiccup mode, auto-recovery
Withstand voltage I/P-O/P: 5656VDC
Working temperature -20~+70°C
Safety standards ANSI/AAMI ES60601-1/ES60601-1-1-11
EMC standards

FCC part 15/CISPR22 Class B

Length of output cable 100cm of UL2468, 18AWG for 5~7.5V; 120cm of UL2468, 22AWG for 9V; 180cm of UL2468, 24AWG for 12V~48V
Dimension (LxWxH) 62.2 x 27.4 x 45.5mm
Standard DC plug P1J: 2.1øx5.5øx11mm / C+, tuning fork type
packing 110pcs/13Kg

Specifications

  • Brand
    Mean Well
  • Series
    GSM Series
  • Power Rating
    12 Watt
  • Output Voltage
    5 Volt
  • Rated Current
    2.4 Ampere
  • Input Voltage
    80V~264V
  • Standards Met
    EAC,FCC,UL
  • Operation Mode
    Constant Voltage
  • Operating Temperature
    -20°C~70°C
  • Warranty
    3 Year
  • Length
    6.22 cm
  • Width
    4.55 cm
  • Height
    2.74 cm
  • Weight
    0.11 kg
