Mean Well HVG-320-48A Power Supply | Adjustable 320W 48V

Description

The HVG-320 is a 320W Mean Well power converter (input range: 180~528VAC).

Key Features

✓ Input voltage range: 180~528VAC
✓ DC output voltage adjustable ±10%
✓ 3.75KVAC reinforced I/O isolation
✓ Protections: Short circuit / Over voltage / Over temperature
✓ Active PFC — meets international energy efficiency regulations
✓ Safety approvals: UL8750 (type”HL”), CSA C22.2 No. 250.13-12, EAC TP TC 004 IP65 or IP67
✓ 3 years warranty

Specifications

Brand

Mean Well
Series

HVG Series
Power Rating

321.6 Watt
Output Voltage

48 Volt
Rated Current

6.7 Ampere
Input Voltage

180V~528V
Standards Met

EAC,FCC,UL
Operation Mode

Constant Current,Constant Voltage
Operating Temperature

-40°C~85°C
Warranty

5 Year
Length

26.2 cm
Width

9 cm
Height

4.38 cm
Weight

2 kg

File Downloads

::specification::

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Frequently Asked Questions

Can I use the HVG-320-48A for 48V linear lighting in commercial projects?

Yes, if the lighting system is designed for 48V constant-current operation and the total load stays within 321.6W and 6.7A. Its 24-48V CC range supports fixtures designed to operate within that constant-current window.

Is the HVG-320-48A suitable for 48V illuminated signage?

It can be used for 48V illuminated signage where the sign load is a constant-current type and remains at or below 321.6W and 6.7A. The IP65 water-resistant enclosure also suits protected outdoor sign applications.

Can this driver be used for architectural lighting that needs 48V constant current?

Yes, for architectural lighting systems that match a 48V constant-current driver and stay inside the 24-48V CC range. The unit is rated for -40°C to +85°C, which helps in demanding indoor or outdoor environments.

How do I calculate the maximum LED strip length for the HVG-320-48A?

Use the formula 321.6W ÷ your strip's rated watts per meter = maximum estimated strip length. Check your strip rated power per meter and verify the strip or fixture is specified for 48V constant-current operation.

How does the HVG-320-48A compare with other 320-series 48V models?

The HVG-320-48A, HVG-320-48AB, and HVG-320-48B are each rated 321.6W, 48V, and 6.7A. The HVG-320-48D2 is also listed at 321.6W in the same series.

Model	Power	Voltage	Current	IP Rating
Mean Well HVG-320-54B Power Supply 320W 54V - Dimmable	324W	54V	6A	IP67	View
Mean Well HVG-320-54AB Power Supply 320W 54V - Adjustable and Dimmable	324W	54V	6A	IP65	View
Mean Well HVG-320-54A Power Supply 320W 54V - Adjustable	324W	54V	6A	IP65	View
