Mean Well IRM-01-9 Switching Power Supply 1W 9V 111mA - Encapsulated
Please Login for Pricing
Description
Description
Features
| Universal AC input / Full range |
| No load power consumption < 0.075W |
| Protections: Short circuit / Overload / Over voltage |
| Compact size |
| Cooling by free air convection |
| Isolation class II |
| High reliability |
| Low cost |
| 3 years warranty |
General Specification
| AC input voltage range | 85~305VAC; 120~430VDC |
| AC inrush current (max.) | Cold start, 5A at 115VAC, 10A at 230VAC |
| Setup, rise, hold up time | 600ms, 30ms, 40ms |
| Overload protection | ≥110% rated output voltage, hiccup mode, auto-recovery |
| Over voltage protection | 115%~135% rated output voltage |
| Withstand voltage | I/P-O/P: 3kVAC |
| Working temperature | -30~+85°C (refer to output derating curve) |
| Leakage current | Less than 0.25mA at 277VAC |
| Safety standards | UL60950-1, TUV EN60950-1 approved,Design refer to IEC60601-1, EN60335-1, EN61558-1/-2-16 |
| EMC standards | EN55022 class B, EN61000-3-2,3, EN61000-4-2,3,4,5,6,8,11,EN55024 |
| Dimension (LxWxH) | PCB mounting style : 33.7x 22.2x 15mm SMD style : 33.7x 22.2x 16 mm |
| Vibration | 10~500Hz, 5G 10min./1 cycle, period for 60 min. each along X, Y, Z axes |
Specifications
Specifications
-
BrandMean Well
-
SeriesIRM Series
-
Power Rating1 Watt
-
Output Voltage9 Volt
-
Rated Current0.11 Ampere
-
Input Voltage85V~305V
-
Standards MetBSMI,CB,CE,EAC,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-30°C~85°C
-
Warranty3 Year
-
Length3.37 cm
-
Width2.22 cm
-
Height1.5 cm
-
Weight0.02 kg
