Mean Well LCM-40BLE Power Supply 42W 350mA 500mA 600mA 700mA(defaul...
Please Login for Pricing
Description
Description
The LCM is a 25W Mean Well DIN rail power converter with a 105mm profile (input range: 6~54V, operating temperature: -30~+85℃).
Key Features
- ✓ 105mm width — DIN rail TS-35 compatible
- ✓ Input voltage range: 6~54V
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Wide operating temperature: -30~+85℃
- ✓ Protections: Short circuit / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: UL8750, CSA C22.2 No.250.13-12, ENEC EN61347-1, EN61347-2-13, EN62384 independent,GB19510.14,GB19510.1, BIS IS15885, EAC TP TC 004
- ✓ 3 years warranty
Specifications
Specifications
-
BrandMean Well
-
SeriesLCM Casambi Series
-
Power Rating42 Watt
-
Output Voltage65 Volt
-
Rated Current0.7 Ampere
-
Input Voltage180V~295V
-
Standards MetCE,UL
-
Operation ModeConstant Current
-
Operating Temperature-25°C~90°C
-
Warranty3 Year
-
Length12.35 cm
-
Width8.15 cm
-
Height2.3 cm
-
Weight0.24 kg
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
What applications is the Mean Well LCM-40BLE best suited for?
The LCM-40BLE is a constant current LED driver for commercial and architectural lighting where wireless dimming or push-dim control is needed. Its 42W rating and selectable output currents make it suitable for LED fittings that need a driver matched to one of the supported current levels.
Does the LCM-40BLE support Casambi control?
Yes. This model supports Casambi and push dimming, which makes it a good fit for projects that want wireless lighting control alongside local dimming functionality. That combination is a key differentiator of the LCM-40BLE within the LCM range.
What output current options are available on the LCM-40BLE?
The LCM-40BLE supports multiple selectable constant current levels: 350mA, 500mA, 600mA, 700mA, 900mA, and 1050mA. The default rated current listed for this model is 700mA.
What input voltage range does the LCM-40BLE accept?
This driver accepts 180 to 295VAC input, and it also supports 254 to 417VDC. That wide input range makes it suitable for commercial mains-powered LED lighting applications using the published electrical limits for this model.
Is the LCM-40BLE suitable for demanding temperature conditions?
The published working temperature reaches up to +90C case temperature, and the product data also lists a minimum ambient figure below freezing. That makes it appropriate for LED lighting environments where thermal performance matters, provided the application stays within the model's stated limits.
How does the LCM-40BLE compare with a fixed-current LED driver?
The main advantage of the LCM-40BLE is flexibility, because one model covers several output current options instead of only one fixed current. It also combines constant current operation with Casambi and push dimming, which can reduce the need to source different driver variants for similar projects.
