Description
Description
Features
Universal AC input (up to 305VAC) / Full range |
Built-in active PFC function |
Fully isolated plastic case |
Built-in 3 in 1 dimming function (1~10VDC, PWM signal or resistance) for D type |
Fully encapsulated with IP67 level |
Class 2 power unit / Pass LPS |
Isolation class II, no F.G. |
Protections: Short circuit / Over current / Over voltage / Over temperature |
Suitable for LED lighting and moving sign applications |
Suitable for dry, damp, and wet location |
Cooling by free air convection |
5 years warranty |
General Specification
AC input voltage range | 90~305VAC ; 127~431VDC |
AC inrush current (max.) | Cold start, 50A |
Over current protection | 95% ~108% constant current, auto-recovery |
Over voltage protection | 110%~150% rated output voltage |
Withstand voltage | I/P - O/P: 3.75kVAC |
Working temperature | -35~+70ºC |
Safety standards | UL8750, ENEC EN61347-1, EN61347-2-13, EN62384, PSE J61347-1, J61347-2-13 approved for LPF-16(D)/25(D); UL8750, TUV EN61347-1, EN61347-2-13, PSE J61347-1, J61347-2-13 approved for LPF-40(D)/60(D)/90(D) |
EMC standards | EN55015, EN61547, EN61000-3-2 class C, EN61000-3-3, EN61000-4-2, 3, 4, 5, 6, 8, 11 |
Connection Input | UL rated, SJTW 18AWGx2C (30cm) |
Connection Output | UL rated, SJTW 18AWGx4C (30cm) |
Dimension (LxWxH)(mm) | 148x 40x 32 |
Specifications
Specifications
-
BrandMean Well
-
SeriesLPF Series
-
Power Rating25.2 Watt
-
Output Voltage12 Volt
-
Rated Current2.1 Ampere
-
Input Voltage90V~305V
-
Standards MetCB,CE,EAC,ENEC,PSE,UL
-
Operation ModeConstant Current,Constant Voltage
-
Operating Temperature-35°C~70°C
-
Warranty5 Year
-
Length14.8 cm
-
Width4 cm
-
Height3.2 cm
-
Weight0.36 kg
