Description
Description
Features
Plastic housing with class II design |
Constant Voltage + Constant Current mode output |
Built-in active PFC function |
No load power consumption <0.15W |
IP67 rating for indoor or outdoor installations |
Typical lifetime >50000hours |
5 years warranty |
General Specification
AC input voltage range | 90~305VAC ; 127~431VDC |
AC inrush current (max.) | Cold start, 60A at 230VAC |
Over current protection | 95% ~108% Constant current limiting, recovers automatically after fault condition is removed |
Over voltage protection | 110%~140% Shut down o/p voltage, re-power on to recover |
Withstand voltage | I/P - O/P: 3.75kVAC |
Working temperature | -40~+80ºC (refer to output derating curve) |
Safety standards | UL8750(type ”HL”), CSA C22.2 No. 250.13-12, ENEC EN61347-1, EN61347-2-13, EN62384 independent,IP67 approved; Design refer to EN60335-1 |
EMC standards | Compliance to EN55015, EN61000-3-2 Class C (@load≥60%) ; EN61000-3-3 |
Connection Input | UL rated, SJTW 18AWGx2C (30cm) |
Connection Output | UL rated, 14AWGx2C (30cm) |
Dimension (LxWxH)(mm) | 191x 63x 37.5 |
Specifications
Specifications
-
BrandMean Well
-
SeriesNPF Series
-
Power Rating122.4 Watt
-
Output Voltage36 Volt
-
Rated Current3.4 Ampere
-
Input Voltage90V~305V
-
Standards MetCB,CCC,CE,EAC,ENEC,UL
-
Operation ModeConstant Current,Constant Voltage
-
Operating Temperature-40°C~90°C
-
Warranty5 Year
-
Length19.1 cm
-
Width6.3 cm
-
Height3.75 cm
-
Weight0.97 kg
