Mean Well PLM-25-700, 700mA Constant Current with PFC - Terminal Block
Please Login for Pricing
Description
Description
The PLM-25 is a 25W Mean Well DIN rail power converter with a 145mm profile (input range: 110~295VAC, operating temperature: -30~+45℃).
Key Features
- ✓ 145mm width — DIN rail TS-35 compatible
- ✓ Input voltage range: 110~295VAC
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Wide operating temperature: -30~+45℃
- ✓ Protections: Short circuit
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: UL8750, CSA C22.2 No. 250.13-12(for Blank type only); ENEC EN61347-1, EN61347-2-13, EN62384, GB19510.14,GB19510.1 (for E type only) ,EAC TP TC 004, IP30
- ✓ 3 years warranty
Specifications
Specifications
-
BrandMean Well
-
SeriesPLM Series
-
Power Rating25.2 Watt
-
Output Voltage42 Volt
-
Rated Current0.7 Ampere
-
Input Voltage110V~295V
-
Standards MetCB,CE,EAC,ENEC,UL
-
Operation ModeConstant Current
-
Operating Temperature-30°C~45°C
-
Warranty2 Year
-
Length14.5 cm
-
Width3.8 cm
-
Height2.2 cm
-
Weight0.13 kg
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
Can I use the PLM-25-700 for a 700mA LED downlight?
Yes, if the downlight needs a constant current driver at 700mA and its LED load stays within the 21-36V constant-current range. This is a constant current model and is not meant for fixed-voltage LED products.
Is the PLM-25-700 a fit for compact LED arrays?
It can be a fit for compact LED arrays that are specified for 700mA constant current operation. The array's total forward voltage must remain within 21-36V, and the driver is rated at 25.2W.
Can this driver be used for constant current signage modules?
Yes, if the signage module assembly is designed around 700mA constant current and the full LED load stays inside the 21-36V CC range. It should not be used where a constant voltage output is required.
What should I check before pairing LEDs with the PLM-25-700?
Check that the LEDs are intended for 700mA constant current operation and that their combined forward voltage falls within 21-36V. The number of LEDs depends on each LED's forward voltage, so there is no single fixed LED count for this driver.
Does the PLM-25-700 have any stated operating limits for ambient temperature?
Yes. The specified operating temperature range is -30°C to +45°C, which defines the ambient range given in the product data.
Other PLM-25 Models
3 other models| Model | Power | Voltage | Current | IP Rating | |
|---|---|---|---|---|---|
| Mean Well PLM-25-350, 350mA Constant Current with PFC - Terminal Block | 25.2W | 80V | 0.35A | Indoor | View |
| Mean Well PLM-25-500, 500mA Constant Current with PFC - Terminal Block | 25W | 56V | 0.5A | Indoor | View |
| Mean Well PLM-25-1050, 1050mA Constant Current with PFC - Terminal Block | 25.2W | 28V | 1.05A | Indoor | View |
