Over 15 years experience of providing support of MEAN WELL Power Supplies
Description
Description
Features
230VAC only or Full range(up to 295VAC) models available |
Built-in active PFC function |
Constant current design |
Protections: Short circuit |
Cooling by free air convection |
Fully isolated plastic case |
Class II power unit, no FG |
Class 2 power unit (for PLM-25-500/700/1050) |
No load power consumption < 0.5W |
High reliability, low cost |
2 years warranty |
General Specification
AC input voltage range | Blank type: 110 ~ 295VAC 156 ~ 417VDC; E type: 180 ~ 295VAC 254~ 417VDC |
AC inrush current (max.) | COLD START 15A(twidth=50μs measured at 50% Ipeak) at 230VAC |
DC adjustment range | |
Current adjustment range | |
Short circuit protection | Hiccup mode, auto-recovery |
Over temperature protection | Hiccup mode, auto-recovery |
Setup time | Blank type: 500ms / 115VAC, 230VAC at full load; E type: 500ms / 230VAC at full load |
Withstand voltage | I/P-O/P: 3.75kVAC |
Working temperature | -30~+45ºC |
Safety standards | UL8750, ENEC EN61347-1,2-13 |
EMC standards | EN55015, EN61000-3-2 class C, EN61000-3-3, EN61000-4-2, 3, 4, 5, 6, 8, 11, EN61547 |
Connection | DG235-7.2-2P |
Dimension (LxWxH) (mm) |
145*38*22mm |
Packing | 60pcs/8.6Kg |
Specifications
Specifications
-
BrandMean Well
-
SeriesPLM Series
-
Power Rating39.9 Watt
-
Output Voltage63 Volt
-
Rated Current0.7 Ampere
-
Input Voltage180V~295V
-
Standards MetCB,CCC,CE,EAC,ENEC,UL
-
Operation ModeConstant Current
-
Operating Temperature-30°C~40°C
-
Warranty2 Year
-
Length17.5 cm
-
Width4.2 cm
-
Height2.4 cm
-
Weight0.18 kg
