Mean Well

Mean Well QP-150-3A Power Supply 150W 5V 3.3V 12V -5V 10A

built-in active PFCPF>0.95quad output
SKU QP-150-3A
Log in to see price Trade pricing & online ordering for account holders
Log in or apply for a trade account →
Available to order
|

Overview

QP-150-3A is the 5V 3.3V 12V -5V output model of this series: rated current 10A 10A 5A 0.6A, typical efficiency 73%.

Features

  • Universal AC input / Full range
  • Built-in active PFC function, PF>0.95
  • Protections: Short circuit / Over load / Over voltage
  • Forced air cooling by built-in DC fan
  • CH4:±Polarity is selectable
  • Fixed switching frequency at 100KHz
  • 3 years warranty

Specifications

QP-150-3ASpecifications from the official datasheet (2024-09-02 edition)

OUTPUT

OUTPUT NUMBER
CH1 CH2 CH3 CH4
DC VOLTAGE
5V 3.3V 12V -5V
RATED CURRENT
10A 10A 5A 0.6A
CURRENT RANGE
3 ~ 15A 0 ~ 15A 0.4 ~ 5A 0 ~ 1A
RATED POWER (max.)
146W
RIPPLE & NOISE (max.)Note.2
100mVp-p 100mVp-p 150mVp-p 150mVp-p
VOLTAGE ADJ. RANGE
CH1: 4.75 ~ 5.5V CH2: 3.14 ~ 3.63V
VOLTAGE TOLERANCENote.3
±3.0% ±3.0% ±6.0% ±5.0%
LINE REGULATION
±1.0% ±1.0% ±2.0% ±1.0%
LOAD REGULATION
±2.0% ±2.0% ±6.0% ±2.0%
SETUP, RISE TIME
800ms, 50ms/230VAC 1800ms, 50ms/115VAC at full load
HOLD UP TIME (Typ.)
24ms/230VAC 24ms/115VAC at full load

INPUT

VOLTAGE RANGE
90 ~ 264VAC 127 ~ 370VDC
FREQUENCY RANGE
47 ~ 63Hz
POWER FACTOR (Typ.)
PF>0.95/230VAC PF>0.98/115VAC at full load
EFFICIENCY (Typ.)
73%
AC CURRENT (Typ.)
2.5A/115VAC 1.2A/230VAC
INRUSH CURRENT (Typ.)
COLD START ≦40A/230V
LEAKAGE CURRENT
<3.5mA / 240VAC

PROTECTION

OVERLOAD
105 ~ 150% rated output power Protection type : Hiccup mode, recovers automatically after fault condition is removed
OVER VOLTAGE
CH1:5.75 ~ 6.75V CH2:3.8 ~ 4.4V Protection type : Shut down o/p voltage, re-power on to recover
OVER TEMPERATURE(OPTION)
Shut down o/p voltage, recovers automatically after temperature goes down

ENVIRONMENT

WORKING TEMP.
-10 ~ +60℃ (Refer to "Derating Curve")
WORKING HUMIDITY
20 ~ 90% RH non-condensing
STORAGE TEMP., HUMIDITY
-20 ~ +85℃ , 10 ~ 95% RH non-condensing
TEMP. COEFFICIENT
± 0.03%/℃ (0~50℃ )
VIBRATION
10 ~ 500Hz, 2G 10min./1cycle, 60min. each along X, Y, Z axes

SAFETY & EMC (Note 4)

SAFETY STANDARDS
UL60950-1, TUV BS EN/EN62368-1, EAC TP TC 004 approved
WITHSTAND VOLTAGE
I/P-O/P:3KVAC I/P-FG:2KVAC O/P-FG:0.5KVAC
ISOLATION RESISTANCE
I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25℃/ 70% RH
EMC EMISSION
Compliance to BS EN/EN55032 (CISPR32) Class B, BS EN/EN61000-3-2,-3, EAC TP TC 020
EMC IMMUNITY
Compliance to BS EN/EN61000-4-2,3,4,5,6,8,11, BS EN/EN55035, light industry level, EAC TP TC 020

OTHERS

MTBF
1763.3K hrs min. Telcordia SR-332 (Bellcore) ; 262.6K hrs min. MIL-HDBK-217F (25℃)
DIMENSION
199*99*50mm (L*W*H)
PACKING
0.93Kg; 20pcs/19.6Kg/1.21CUFT
Test conditions and notes5
  1. 1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25℃ of ambient temperature.
  2. 2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1μF & 47μF parallel capacitor.
  3. 3. Tolerance : includes set up tolerance, line regulation and load regulation.
  4. 4. The power supply is considered a component which will be installed into a final equipment. All the EMC tests are been executed by mounting the unit on a 360mm*360mm metal plate with 1mm of thickness. The final equipment must be re-confirmed that it still meets EMC directives. For guidance on how to perform these EMC tests, please refer to “EMI testing of component power supplies.” (as available on https://www.meanwell.com//Upload/PDF/EMI_statement_en.pdf )
  5. 5. The ambient temperature derating of 3.5℃/1000m with fanless models and of 5℃/1000m with fan models for operating altitude higher than 2000m(6500ft).

Technical drawings

QP-150-3A Block Diagram
Block Diagram
QP-150-3A Derating Curve
Derating Curve
QP-150-3A Mechanical Specification
Mechanical Specification

Downloads

FAQ

Can I use the QP-150-3A for industrial control hardware that needs 5V, 3.3V, 12V, and -5V rails?

Yes, the QP-150-3A is a quad-output constant-voltage supply whose product name identifies 5V, 3.3V, 12V, and -5V outputs. With 146W total power and 10A on the 5V rail, it suits higher-load control and embedded systems that need several low-voltage rails from one power source.

Is the QP-150-3A appropriate for embedded computing or industrial PC assemblies with mixed DC rails?

It is well matched to mixed-rail systems because it combines 5V, 3.3V, 12V, and -5V outputs in one unit. The built-in active PFC with PF greater than 0.95 also makes it more suitable for higher-power AC-fed equipment than smaller multi-output supplies.

Would the QP-150-3A work for factory test equipment with both digital and legacy interface circuits?

Yes, this model is relevant for test and control equipment that uses 5V and 3.3V digital rails, 12V support circuits, and a -5V rail in the same chassis. Its 146W rating provides more headroom than the smaller 100W class siblings listed in the same family.

Can the QP-150-3A fit larger automation enclosures that need more output capacity than compact PT models?

Yes, it is aimed at larger multi-output loads with 146W total power and 10A on the 5V rail. Its 199.0 × 99.0 × 50.0 mm size and 0.93 kg weight reflect that higher-capacity class.

How does the QP-150-3A compare with the other listed QP siblings?

The supplied series list includes QP-100-3A, QP-100-3B, QP-100-3C, QP-100-3D, QP-100B, and QP-100C at 100W with 5V; QP-100D at 100W with -12V and 0.6A; QP-100F at 100W with -15V and 0.6A; QP-150-3B at 150.2W with 5V and 10A; QP-150-3C at 152W with 5V and 10A; QP-150-3D at 146W; QP-150B with no specs shown; QP-150C at 146W; QP-150D at 146W; QP-150F at 146W; QP-200-3A at 200W with 5V and 15A; QP-200-3B at 203.4W; QP-200-3C at 203.4W; QP-200-3D at 203.9W with 5V and 10A; QP-200-3E at 203.4W; QP-200D at 203.4W with 5V and 15A; QP-200F at 202.5W with 5V and 15A; QP-320D and QP-320F at 316W with 5V and 20A; QP-375-24B and QP-375-24C at 375W with 24V; QP-375-5A, QP-375-5B, QP-375-5D, and QP-375-5E at 375W with 5V; and QP-375-5C at 378W with 5V and 30A. The QP-150-3A itself is 146W with 5V and 10A, and its product name identifies the additional outputs as 3.3V, 12V, and -5V.

Is the QP-150-3A suitable for outdoor use or harsher temperature conditions?

The product specs give an operating temperature range of -10°C to +60°C, but they do not provide an IP rating. That means outdoor or exposed use should be evaluated carefully, with the application kept within -10°C to +60°C and ingress protection handled separately if required.
