Mean Well RPS-400-18-C Green Power Supply W 18V 13.9A - Medical Pow...
Please Login for Pricing
Description
Description
The RPS-400-18 is a 400W Mean Well power converter (input range: 80~264VAC, operating temperature: -30~+70℃).
Key Features
- ✓ Input voltage range: 80~264VAC
- ✓ DC output voltage adjustable ±10%
- ✓ 4KVAC reinforced I/O isolation
- ✓ Wide operating temperature: -30~+70℃
- ✓ Protections: Overload / Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: IEC60601-1, TUV EN60601-1, EAC TP TC 004 , UL ANSI / AAMI ES60601-1 (3.1 version), CAN/CSA-C22.2 No. 60601-1:14 - Edition 3
- ✓ 3 years warranty
Specifications
Specifications
-
BrandMean Well
-
SeriesRPS Series
-
Power Rating250.2 Watt
-
Output Voltage18 Volt
-
Rated Current13.9 Ampere
-
Input Voltage80V~264V
-
Standards MetCB,CE,cUL,EAC,SHIDE
-
Operation ModeConstant Voltage
-
Operating Temperature-30°C~70°C
-
Warranty3 Year
-
Length13 cm
-
Width8.6 cm
-
Height4.3 cm
-
Weight0.51 kg
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
Can I use the RPS-400-18-C in an 18V medical cart or portable clinical device?
Yes, if the device is built for 18V constant-voltage input and remains within 13.9A and 250.2W. It is a medical power supply, so it is targeted at equipment categories where medical approvals and low leakage current matter.
Is this a fit for 18V industrial monitoring or control hardware?
It can be a fit for industrial monitoring, control, or instrumentation hardware that specifies 18V DC input. The supply provides up to 13.9A, and the 80-264VAC input range supports broad AC source compatibility.
Can the RPS-400-18-C power a higher-load 18V embedded system?
It is suited to embedded systems that use a regulated 18V rail and need more output than lower-power models can provide. The available 250.2W gives meaningful headroom for consolidated 18V loads up to 13.9A.
Would this model make sense for compact automation equipment that still needs 18V headroom?
This version combines 18V output at 13.9A with a 130.0 x 86.0 x 43.0 mm footprint and a 0.51 kg weight. That makes it relevant for equipment builders balancing enclosure space against the need for 250.2W output.
Can I use the RPS-400-18-C in outdoor cabinets or washdown areas?
The unit is rated for -30C to +70C operation, but no IP rating is listed in the provided specifications. That means it is better matched to indoor or protected enclosure use than to exposed outdoor or washdown conditions.
