Mean Well SFT01L-12 DC-DC Converter - 1W 5V DC in 12V out
Please Login for Pricing
Description
Description
- 3000VDC I/O isolation
- Internal SMD technology
- Protection: Short circuit
- Cooling by free air convection
- Non-conductive plastic case
- SMD package styles
- 100% full load burn-in test
- Low cost / High reliability
- Approved: UL / CUL
- 1 year warranty
Specifications
Specifications
-
BrandMean Well
-
SeriesSFTN Series
-
Power Rating1 Watt
-
Output Voltage12 Volt
-
Rated Current0.08 Ampere
-
Input Voltage4.5V~5.5V
-
Operating Temperature-40°C~85°C
-
Warranty1 Year
-
Length15 cm
-
Width10 cm
-
Height2 cm
-
Weight1 kg
