Mean Well SKM10W8-03 10W DC-DC Converter 3.3VDC
Please Login for Pricing
Description
Description
The SKM10W8-03 is a 10W single output DC-DC converter in a compact 1"×1" SIP package, delivering 3.3V at 3.03A. With an 85% typical efficiency and a wide 4:1 input voltage range (9–36V or 18–75V depending on input), it is suitable for industrial, telecom, and battery-powered applications.
Key Features
- ✓10W output power, single output
- ✓Output: 3.3V at 3.03A
- ✓8:1 ultra-wide input voltage range
- ✓85% typical efficiency
- ✓3000VDC (3kV) isolation voltage
- ✓Compact 1"×1" SIP package (25.4×25.4×12.2mm)
- ✓Operating temperature: −40°C to +85°C
- ✓Short circuit, over voltage, over current protection
Specifications
Specifications
-
BrandMean Well
-
Standards MetCE,EMC
-
Operation ModeConstant Voltage
-
Length2.54 cm
-
Width2.54 cm
-
Height1.22 cm
-
Weight0.02 kg
