Can I use the SPUN02N-05 to step down a 21.6~26.4V source to 5V for industrial electronics?

Yes, this converter is specified for 21.6~26.4V input and delivers a constant 5V output at 2W. That makes it suitable for low-power industrial electronics, control interfaces, and embedded boards that need 5V from a higher-voltage source.

Is the SPUN02N-05 appropriate for 24V-style automation systems that need a low-power 5V rail?

It is aligned with that use case because the input range is 21.6~26.4V and the output is 5V constant voltage. The 2W rating means it fits low-power logic, monitoring, and interface functions rather than larger 5V loads.

Can this converter be used on compact monitoring or embedded control boards?

Yes, the module is small at 19.6 × 10.2 × 7.2 mm and weighs 0.0027 kg, which helps in compact board-level designs. Its regulated 5V output is appropriate for low-power embedded and monitoring electronics within the 2W limit.

Is the SPUN02N-05 suitable for outdoor cabinets or only protected enclosures?

The operating temperature range is -40°C to +105°C, so the temperature spec supports demanding conditions in protected equipment. No IP rating is listed, so these specs do not indicate suitability for exposed outdoor use.

How does the SPUN02N-05 compare with the other SPUN02N models?

The SPUN02N series entries listed here are all 2W models with different outputs. SPUN02N-05 is 5V with 400A output current, SPUN02N-12 is 12V with 167A, and SPUN02N-15 is 15V with 134A.

Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Mean Well

Mean Well SPUN02N-05 DC-DC Converter - 2W - 21.6~26.4V in 5V out

SKU:

SPUN02N-05

Log in to see price Trade pricing & online ordering for account holders

Notify me when it's back in stock

The SPUN02N is a 2W Mean Well power converter (input range: 4.5~5.5Vdc).

Key Features

✓ Input voltage range: 4.5~5.5Vdc
✓ 3KVDC reinforced I/O isolation
✓ Protections: Short circuit / Overload
✓ Safety approvals: EAC TP TC 004
✓ 3 years warranty

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Model	Power	Voltage	Current	IP Rating
Mean Well SPUN02N-15 DC-DC Converter - 2W - 21.6~26.4V in 15V out	2W	15V	0.13A	Indoor	View
Mean Well SPUN02N-12 DC-DC Converter - 2W - 21.6~26.4V in 12V out	2W	12V	0.16A	Indoor	View
Mean Well SPUN02M-15 DC-DC Converter - 2W - 10.8~13.2V in 15V out	2W	15V	0.13A	Indoor	View
Mean Well SPUN02M-12 DC-DC Converter - 2W - 10.8~13.2V in 12V out	2W	12V	0.16A	Indoor	View
Mean Well SPUN02M-05 DC-DC Converter - 2W - 10.8~13.2V in 5V out	2W	5V	0.4A	Indoor	View
Mean Well SPUN02L-15 DC-DC Converter - 2W - 4.5~5.5V in 15V out	2W	15V	0.13A	Indoor	View
Mean Well SPUN02L-12 DC-DC Converter - 2W - 4.5~5.5V in 12V out	2W	12V	0.16A	Indoor	View
Mean Well SPUN02L-05 DC-DC Converter - 2W - 4.5~5.5V in 5V out	2W	5V	0.4A	Indoor	View
