Mean Well XDR-120-48LA High-End Ultra Slim Industrial Din Rail Power Supply 120W 48V with Lever Actuated Connector 2.5A
Notify me when it's back in stock
Mean Well XDR-120-48LA High-End Ultra Slim Industrial Din Rail Powe...
Please Login for Pricing
Description
Description
Key Features
- ✓85~305Vac input range (277Vac available)
- ✓Global certificates in multi-fields(ITE 62368-1, Industrial 61558-1/-2-16, 61010) & Marine DNV, SEMI47, CID2 HazLoc approved
- ✓30mm ultra slim width
- ✓High efficiency up to 94% and no-load power dissipation 0.9W~2W by R.C.
- ✓200% peak power capability
- ✓600% transient peak current capability
- ✓Built-in constant current limiting circuit
- ✓Protections: Short circuit / Overload / Over voltage / Over temperature
- ✓Fanless design, cooling by free air convection
- ✓Over voltage category III (OVC III)
- ✓-40°~+85°C wide range operation temperature (>+60°C derating)
- ✓Operating altitude up to 5000 meters
- ✓Built-in remote ON/OFF control and DC OK relay contact
- ✓Ultra low inrush current <6~15A
- ✓Tool free terminal block (LA Type)
- ✓Conformal coating
- ✓Can be installed on DIN rail TS-35/7.5 or 15
- ✓5 years warranty
Specifications
Specifications
-
BrandMean Well
-
Input Voltage85V~305V
-
Standards MetCB,CCC,CE,cUL,DEKRA,EAC,KC,RCM
-
Operating Temperature-40°C~85°C
-
Length11.6 cm
-
Width3 cm
-
Height12.52 cm
-
Weight0.6 kg
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
What is the Mean Well XDR-120-48LA used for?
The XDR-120-48LA is a 120W industrial DIN rail power supply for 48V DC loads. It is suited to control panels, industrial equipment, automation systems, and other applications that need a slim DIN rail power source with broad AC input support.
What are the main output specifications of the XDR-120-48LA?
This model provides a 48V DC output with a rated current of 2.5A. Its total rated power is 120W, making it appropriate for 48V systems that fit within that power and current range.
How slim is the XDR-120-48LA compared with typical DIN rail power supplies?
The XDR-120-48LA has an ultra slim 30mm width. That makes it useful where panel space is limited and a compact DIN rail form factor is important.
What input range does the XDR-120-48LA support?
The XDR-120-48LA supports an 85-305Vac input range, with 277Vac availability noted in the product specifications. This wide input range helps the same model fit a variety of industrial AC supply environments.
Can the XDR-120-48LA operate in harsh environments?
This model is rated for an operating temperature range from -40°C to 85°C. It also lists approvals including Marine DNV, SEMI47, and CID2 HazLoc, which makes it relevant for demanding industrial and specialized environments where those approvals are required.
What efficiency and standby characteristics does the XDR-120-48LA provide?
The XDR-120-48LA is specified with efficiency up to 94%. Its no-load power dissipation is listed as 0.9W to 2W by R.C., supporting lower idle energy use in systems that spend time unloaded.
What protection features are included with the XDR-120-48LA?
The listed protections include short circuit, overload, over voltage, and over temperature protection. It also includes a built-in constant current limiting circuit, plus 200% peak power capability and 600% transient peak current capability.
What warranty applies to the XDR-120-48LA?
The XDR-120-48LA has a listed warranty period of 5 years. For buyers comparing industrial DIN rail power supplies, that warranty period is one of the key lifecycle considerations for this model.
