Mean Well XDR-240-12 High-End Ultra Slim Industrial Din Rail Power Supply 240W 12V 20A
Notify me when it's back in stock
Mean Well XDR-240-12 High-End Ultra Slim Industrial Din Rail Power ...
Please Login for Pricing
Description
Description
Key Features
- ✓85~305Vac input range (277Vac available)
- ✓Global certificates in multi-fields(ITE 62368-1, Industrial 61558-1/-2-16, 61010) & Marine DNV, SEMI47, CID2 HazLoc approved
- ✓40mm ultra slim width
- ✓High efficiency up to 95.5% and no-load power dissipation 1W~2.5W by R.C.
- ✓200% peak power capability
- ✓600% transient peak current capability
- ✓Built-in active current sharing for parallel operation up to 960W (3+1)
- ✓MODBus communication interface for control, setting, and monitoring
- ✓Built-in constant current limiting circuit
- ✓Protections: Short circuit / Overload / Over voltage / Over temperature
- ✓Fanless design, cooling by free air convection
- ✓Over voltage category III (OVC III)
- ✓-40°~+85°C wide range operation temperature (>+60°C derating)
- ✓Operating altitude up to 5000 meters
- ✓Built-in remote ON/OFF control and DC OK relay contact
- ✓Ultra low inrush current <6~15A
- ✓Tool free terminal block (LA Type)
- ✓Conformal coating
- ✓Can be installed on DIN rail TS-35/7.5 or 15
- ✓5 years warranty
Specifications
Specifications
-
BrandMean Well
-
Input Voltage85V~305V
-
Standards MetCB,CCC,CE,cUL,DEKRA,EAC,KC,RCM
-
Operating Temperature-40°C~85°C
-
Length11.6 cm
-
Width4 cm
-
Height12.52 cm
-
Weight0.79 kg
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
What are the key output ratings for the Mean Well XDR-240-12?
The XDR-240-12 is rated for 240W output power with a 12V output. Its rated output current is 20A, making it suitable for industrial DC power applications that require a 12V rail within this power range.
What types of applications is the XDR-240-12 intended for?
This model is part of Mean Well's industrial DIN rail power supply range and is listed in DIN rail, slim DIN rail, power supply, and DC-DC converter related product categories. Its approvals for industrial, ITE, marine DNV, SEMI47, and CID2 HazLoc environments make it relevant for demanding commercial and industrial systems where those certifications matter.
What makes the XDR-240-12 different from a standard DIN rail power supply?
The XDR-240-12 is described as a high-end ultra slim industrial DIN rail power supply with a 40mm width. It also offers up to 95.5% efficiency, 200% peak power capability, 600% transient peak current capability, and a MODBus communication interface for control, setting, and monitoring.
What operating temperature range does the XDR-240-12 support?
The specified operating temperature range is -40°C to 85°C. This wide range supports use in industrial environments where equipment may be exposed to low startup temperatures or elevated enclosure temperatures.
Can the XDR-240-12 be used in systems that need international or industry-specific approvals?
Yes. The product description lists global certificates across multiple fields, including ITE 62368-1, Industrial 61558-1/-2-16, 61010, Marine DNV, SEMI47, and CID2 HazLoc approval. Buyers should confirm the required approval set against their project or compliance documentation before purchase.
What input voltage range does the XDR-240-12 accept?
The XDR-240-12 has an 85~305Vac input range, with 277Vac available according to the product description. This broad AC input range can help support systems deployed across different regional or industrial power environments.
Does the XDR-240-12 support higher power systems?
The product description states that it has built-in active current sharing for parallel operation up to 960W, described as 3+1. This makes the model relevant for systems where multiple compatible units are used to support higher total power capacity or redundancy requirements.
What are the warranty period and weight for the XDR-240-12?
The XDR-240-12 has a listed warranty period of 5 years. Its listed weight is 0.7900 kg, which may be useful when evaluating enclosure load, shipping, or bill-of-material details.
