Over 15 years experience of providing support of MEAN WELL Power Supplies
Image shown is a representation only. Exact specifications should be obtained from the product datasheet.
Mean Well XDR-240-12PI High-End Ultra Slim Industrial Din Rail Power Supply 240W 12V with Push In Connector 20A
Notify me when it's back in stock
Mean Well XDR-240-12PI High-End Ultra Slim Industrial Din Rail Powe...
Please Login for Pricing
Description
Description
Key Features
- ✓85~305Vac input range (277Vac available)
- ✓Global certificates in multi-fields(ITE 62368-1, Industrial 61558-1/-2-16, 61010) & Marine DNV, SEMI47, CID2 HazLoc approved
- ✓40mm ultra slim width
- ✓High efficiency up to 95.5% and no-load power dissipation 1W~2.5W by R.C.
- ✓200% peak power capability
- ✓600% transient peak current capability
- ✓Built-in active current sharing for parallel operation up to 960W (3+1)
- ✓MODBus communication interface for control, setting, and monitoring
- ✓Built-in constant current limiting circuit
- ✓Protections: Short circuit / Overload / Over voltage / Over temperature
- ✓Fanless design, cooling by free air convection
- ✓Over voltage category III (OVC III)
- ✓-40°~+85°C wide range operation temperature (>+60°C derating)
- ✓Operating altitude up to 5000 meters
- ✓Built-in remote ON/OFF control and DC OK relay contact
- ✓Ultra low inrush current <6~15A
- ✓Tool free terminal block (LA Type)
- ✓Conformal coating
- ✓Can be installed on DIN rail TS-35/7.5 or 15
- ✓5 years warranty
Specifications
Specifications
-
BrandMean Well
-
Input Voltage85V~305V
-
Standards MetCB,CCC,CE,cUL,DEKRA,EAC,KC,RCM
-
Operating Temperature-40°C~85°C
-
Length11.6 cm
-
Width4 cm
-
Height12.52 cm
-
Weight0.79 kg
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
What is the output power and voltage of the Mean Well XDR-240-12PI?
The XDR-240-12PI is rated for 240 W output power with a 12 VDC output. Its rated output current is 20 A, making it suitable for 12 V industrial control and automation loads within that power range.
Is the XDR-240-12PI suitable for space-constrained DIN rail panels?
Yes. This model is described as an ultra slim DIN rail power supply with a 40 mm width, which helps reduce panel space usage compared with wider supplies in the same general power class.
What input voltage range does the XDR-240-12PI support?
The XDR-240-12PI supports an 85 to 305 Vac input range. The provided product data also notes that 277 Vac is available, which is useful for industrial and commercial power systems that use higher AC mains voltages.
What certifications or approvals are listed for the XDR-240-12PI?
The listed approvals include ITE 62368-1, Industrial 61558-1/-2-16, 61010, Marine DNV, SEMI47, and CID2 HazLoc. These approvals make the model relevant for industrial, marine, semiconductor, and hazardous-location applications where those standards are required.
Can the XDR-240-12PI be used in high-temperature or cold environments?
The listed operating temperature range is -40 °C to 85 °C. That wide range supports use in demanding industrial environments, provided the application stays within the product's specified ratings.
How efficient is the XDR-240-12PI?
The XDR-240-12PI has high efficiency of up to 95.5%. The product data also lists no-load power dissipation of 1 W to 2.5 W by R.C., which may matter in systems where standby consumption is reviewed.
Does the XDR-240-12PI support parallel operation?
Yes. The listed features include built-in active current sharing for parallel operation up to 960 W in a 3+1 configuration. This can be useful for higher-power systems or redundancy designs that require compatible current sharing behavior.
What makes the XDR-240-12PI different from a basic DIN rail power supply?
Compared with a basic DIN rail supply, this model has a high-end feature set including a 40 mm ultra slim width, up to 95.5% efficiency, 200% peak power capability, 600% transient peak current capability, active current sharing, and a MODBus communication interface. It also carries multiple listed approvals for industrial, marine, semiconductor, and hazardous-location use cases.
Does the XDR-240-12PI include communication features?
Yes. The listed features include a MODBus communication interface for control, setting, and monitoring. This makes the XDR-240-12PI more suitable for monitored industrial power systems than models without communication support.
