Mean Well XDR-240-36PI High-End Ultra Slim Industrial Din Rail Power Supply 239.76W 36V with Push In Connector 6.66A
Notify me when it's back in stock
Mean Well XDR-240-36PI High-End Ultra Slim Industrial Din Rail Powe...
Please Login for Pricing
Description
Description
Key Features
- ✓85~305Vac input range (277Vac available)
- ✓Global certificates in multi-fields(ITE 62368-1, Industrial 61558-1/-2-16, 61010) & Marine DNV, SEMI47, CID2 HazLoc approved
- ✓40mm ultra slim width
- ✓High efficiency up to 95.5% and no-load power dissipation 1W~2.5W by R.C.
- ✓200% peak power capability
- ✓600% transient peak current capability
- ✓Built-in active current sharing for parallel operation up to 960W (3+1)
- ✓MODBus communication interface for control, setting, and monitoring
- ✓Built-in constant current limiting circuit
- ✓Protections: Short circuit / Overload / Over voltage / Over temperature
- ✓Fanless design, cooling by free air convection
- ✓Over voltage category III (OVC III)
- ✓-40°~+85°C wide range operation temperature (>+60°C derating)
- ✓Operating altitude up to 5000 meters
- ✓Built-in remote ON/OFF control and DC OK relay contact
- ✓Ultra low inrush current <6~15A
- ✓Tool free terminal block (LA Type)
- ✓Conformal coating
- ✓Can be installed on DIN rail TS-35/7.5 or 15
- ✓5 years warranty
Specifications
Specifications
-
BrandMean Well
-
Input Voltage85V~305V
-
Standards MetCB,CCC,CE,cUL,DEKRA,EAC,KC,RCM
-
Operating Temperature-40°C~85°C
-
Length11.6 cm
-
Width4 cm
-
Height12.52 cm
-
Weight0.79 kg
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
What output does the Mean Well XDR-240-36PI provide?
The XDR-240-36PI is rated for 239.76W of output power with a 36V DC output. Its rated output current is 6.66A, making it suitable for 36V industrial control and automation loads within that power range.
What types of applications is the XDR-240-36PI intended for?
This model is designed for industrial DIN rail power applications where a compact 36V power source is needed. Its listed approvals include industrial, ITE, marine DNV, SEMI47, and Class I Division 2 hazardous location coverage, which makes it relevant for demanding commercial and industrial environments.
Why choose the XDR-240-36PI over a standard DIN rail power supply?
The XDR-240-36PI offers higher-end features than many basic DIN rail supplies, including a 40mm ultra-slim width, efficiency up to 95.5%, 200% peak power capability, and 600% transient peak current capability. It also supports active current sharing for parallel operation up to 960W in a 3+1 configuration.
What operating temperature range does the XDR-240-36PI support?
The specified operating temperature range is -40°C to 85°C. That wide range makes this model appropriate for industrial environments where ambient temperature can vary significantly.
Can the XDR-240-36PI be used with international AC input power?
Yes. The listed input range is 85 to 305Vac, with 277Vac available, so it is designed for broad AC input compatibility. Buyers should still confirm the full system requirements against the product datasheet and local compliance needs.
Does the XDR-240-36PI support monitoring or communication features?
Yes. This model includes a MODBus communication interface for control, setting, and monitoring. That feature can be useful in industrial systems where power supply status and operating data need to be integrated into a larger control platform.
What is the efficiency of the XDR-240-36PI?
The XDR-240-36PI has listed efficiency up to 95.5%. It also has no-load power dissipation listed from 1W to 2.5W by remote control, which can matter in systems where standby consumption is monitored.
What warranty comes with the XDR-240-36PI?
The XDR-240-36PI has a listed warranty period of 5 years. For B2B purchasing, this can help standardize expectations for support and lifecycle planning.
