Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Mean Well XDR-480-12 High-End Ultra Slim Industrial Din Rail Power Supply 360W 12V 30A

Q: What are the key output specifications of the Mean Well XDR-480-12?

The Mean Well XDR-480-12 is a 360W industrial DIN rail power supply with a 12V output and 30A rated current. It belongs to the XDR high-end ultra slim DIN rail power supply family and is designed for industrial power applications.

Q: What types of applications is the XDR-480-12 suitable for?

The XDR-480-12 is suited for industrial DIN rail power systems that require a compact 12V DC power source. Its listed approvals include ITE, industrial, marine DNV, SEMI47, and CID2 HazLoc, making it relevant for demanding commercial and industrial environments.

Q: What makes the XDR-480-12 an ultra slim DIN rail power supply?

This model has a listed width of 48mm, which makes it compact for a 360W DIN rail power supply. That slim form factor can help when panel space is limited and a 12V industrial power supply is required.

Q: What operating temperature range does the XDR-480-12 support?

The XDR-480-12 has a specified operating temperature range from -40°C to 85°C. This wide range supports use in harsh industrial environments where equipment may face low or elevated ambient temperatures.

Q: Can the XDR-480-12 be used in systems with wide AC input requirements?

Yes. The product description lists an 85 to 305Vac input range and notes 277Vac availability, which makes it suitable for systems that require broad AC input support.

Q: Does the XDR-480-12 support peak power capability?

Yes. The XDR-480-12 lists 200% peak power capability and 600% transient peak current capability. These features are useful for applications with short-duration surge or startup demand, within the product's specified operating limits.

Q: Does the XDR-480-12 support parallel operation?

Yes. The product description states that it includes built-in active current sharing for parallel operation up to 1920W in a 3+1 configuration. This makes it relevant for higher-power systems that use multiple compatible units.

Q: What communication features are listed for the XDR-480-12?

The XDR-480-12 includes a MODBus communication interface for control, setting, and monitoring. This can be useful in industrial systems where power supply status and configuration need to be integrated into broader monitoring workflows.

Q: What warranty and weight are specified for the XDR-480-12?

The XDR-480-12 has a listed warranty period of 5 years. Its specified weight is 1.1 kg, which is relevant for panel planning and product comparison.

48mm ultra slim, high efficiency up to 96%, 200% peak power capability, 600% transient peak current capability, parallel operation up to 1920W, MODBus communication, ultra low inrush current

SKU:

XDR-480-12

Please for Pricing

Notify me when it's back in stock

Description

Key Features

✓85~305Vac input range (277Vac available)
✓Global certificates in multi-fields(ITE 62368-1, Industrial 61558-1/-2-16, 61010) & Marine DNV, SEMI47, CID2 HazLoc approved
✓48mm ultra slim width
✓High efficiency up to 96% and no-load power dissipation 1W~3W by R.C.
✓200% peak power capability
✓600% transient peak current capability
✓Built-in active current sharing for parallel operation up to 1920W (3+1)
✓MODBus communication interface for control, setting, and monitoring
✓Built-in constant current limiting circuit
✓Protections: Short circuit / Overload / Over voltage / Over temperature
✓Fanless design, cooling by free air convection
✓Over voltage category III (OVC III)
✓-40°~+85°C wide range operation temperature (>+60°C derating)
✓Operating altitude up to 5000 meters
✓Built-in remote ON/OFF control and DC OK relay contact
✓Ultra low inrush current <6~15A
✓Tool free terminal block (LA Type)
✓Conformal coating
✓Can be installed on DIN rail TS-35/7.5 or 15
✓5 years warranty

Specifications

Brand

Mean Well
Input Voltage

85V~305V
Standards Met

CB,CCC,CE,cUL,DEKRA,EAC,KC,RCM
Operating Temperature

-40°C~85°C
Length

12.5 cm
Width

4.8 cm
Height

12.52 cm
Weight

1.1 kg
