Over 15 years experience of providing support of MEAN WELL Power Supplies
Image shown is a representation only. Exact specifications should be obtained from the product datasheet.
Mean Well XDR-480-12PI High-End Ultra Slim Industrial Din Rail Power Supply 360W 12V with Push In Connector 30A
Notify me when it's back in stock
Mean Well XDR-480-12PI High-End Ultra Slim Industrial Din Rail Powe...
Please Login for Pricing
Description
Description
Key Features
- ✓85~305Vac input range (277Vac available)
- ✓Global certificates in multi-fields(ITE 62368-1, Industrial 61558-1/-2-16, 61010) & Marine DNV, SEMI47, CID2 HazLoc approved
- ✓48mm ultra slim width
- ✓High efficiency up to 96% and no-load power dissipation 1W~3W by R.C.
- ✓200% peak power capability
- ✓600% transient peak current capability
- ✓Built-in active current sharing for parallel operation up to 1920W (3+1)
- ✓MODBus communication interface for control, setting, and monitoring
- ✓Built-in constant current limiting circuit
- ✓Protections: Short circuit / Overload / Over voltage / Over temperature
- ✓Fanless design, cooling by free air convection
- ✓Over voltage category III (OVC III)
- ✓-40°~+85°C wide range operation temperature (>+60°C derating)
- ✓Operating altitude up to 5000 meters
- ✓Built-in remote ON/OFF control and DC OK relay contact
- ✓Ultra low inrush current <6~15A
- ✓Tool free terminal block (LA Type)
- ✓Conformal coating
- ✓Can be installed on DIN rail TS-35/7.5 or 15
- ✓5 years warranty
Specifications
Specifications
-
BrandMean Well
-
Input Voltage85V~305V
-
Standards MetCB,CCC,CE,cUL,DEKRA,EAC,KC,RCM
-
Operating Temperature-40°C~85°C
-
Length12.5 cm
-
Width4.8 cm
-
Height12.52 cm
-
Weight1.1 kg
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
What type of applications is the XDR-480-12PI designed for?
The Mean Well XDR-480-12PI is a DIN rail industrial power supply for B2B power systems that need a compact 12 V DC source. Its listed approvals include ITE, industrial, marine DNV, SEMI47, and CID2 HazLoc, making it suitable for demanding industrial and commercial environments where those certifications matter.
How much output does this model provide?
This model is listed with a 12 V DC output and 30 A rated current. The supplied product data also lists a 480 W rating while the product name identifies 360 W at 12 V, so buyers should confirm the exact continuous power requirement against the SKU documentation before specifying it.
Is the XDR-480-12PI suitable for narrow control panels?
Yes. This model is described as an ultra slim DIN rail power supply with a 48 mm width, which can help reduce panel space compared with wider industrial supplies in the same general class.
What input voltage range does the XDR-480-12PI support?
The listed input range is 85 to 305 Vac, with 277 Vac availability noted in the product description. This broad AC input range makes the model relevant for global industrial systems where the supply voltage may vary by site or region.
Can this power supply operate in harsh temperature conditions?
The listed operating temperature range is -40 °C to 85 °C. That wide range makes the XDR-480-12PI a fit for many industrial cabinets and equipment environments subject to cold starts or elevated ambient temperatures.
Does the XDR-480-12PI support parallel operation?
Yes. The product description lists built-in active current sharing for parallel operation up to 1920 W in a 3+1 configuration. This is useful for systems that require higher available power or redundancy planning within the limits of the approved system design.
What efficiency is listed for this model?
The XDR-480-12PI is listed with high efficiency up to 96%. The description also notes no-load power dissipation of 1 W to 3 W by remote control, which may matter for systems where standby consumption is reviewed.
What warranty does the XDR-480-12PI include?
This model is listed with a 5 year warranty period. For industrial buyers, that warranty term can be an important factor when comparing lifecycle cost and support expectations across DIN rail power supplies.
