Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Mean Well XDR-480-36 High-End Ultra Slim Industrial Din Rail Power Supply 478.8W 36V 13.3A

Q: What is the output voltage and power rating of the Mean Well XDR-480-36?

The XDR-480-36 is rated for 36V output and 478.8W of power. Its rated output current is 13.3A, making it suitable for higher-power industrial DC supply requirements within those limits.

Q: What types of applications is the XDR-480-36 intended for?

This model is designed for industrial DIN rail power applications where a 36V DC output and compact form factor are required. Its certifications cover multiple fields, including ITE, industrial, marine DNV, SEMI47, and CID2 hazardous location approval.

Q: How slim is the XDR-480-36 compared with typical industrial DIN rail power supplies?

The XDR-480-36 has an ultra slim 48mm width. That makes it a strong fit for control cabinets or industrial panels where space efficiency is an important purchasing factor.

Q: What temperature range does the XDR-480-36 support?

The specified operating temperature range for this model is -40°C to 85°C. This wide range supports demanding industrial environments where equipment may be exposed to low or elevated ambient temperatures.

Q: Does the XDR-480-36 support parallel operation?

Yes. The product description lists built-in active current sharing for parallel operation up to 1920W in a 3+1 configuration.

Q: What input voltage range is listed for the XDR-480-36?

The listed input range is 85~305Vac, with 277Vac availability noted in the product description. This broad AC input range supports use across many industrial power environments.

Q: What efficiency is specified for the XDR-480-36?

The XDR-480-36 is specified with high efficiency up to 96%. The description also lists no-load power dissipation of 1W to 3W by R.C.

Q: What warranty period and weight are listed for this model?

The XDR-480-36 has a listed warranty period of 5 years. Its listed weight is 1.1kg.

48mm ultra slimhigh efficiency up to 96%200% peak power capability600% transient peak current capabilityparallel operation up to 1920WMODBus communicationultra low inrush current

SKU XDR-480-36

Log in to see price Trade pricing & online ordering for account holders

Notify me when it's back in stock

The Mean Well XDR-480-36 is a 480W ultra-slim DIN-rail power supply delivering 36V DC at up to 13.3A. It is built for industrial control cabinets where panel width is at a premium — mounting directly to standard TS-35 DIN rail and cooling by free-air convection, with no fan to service. Built-in active PFC and a full-range 85~305VAC input suit it to single-phase supplies worldwide.

Rated for operation from -40°C to 85°C, the XDR-480-36 carries CB, CCC, CE, cUL, DEKRA, EAC, KC and RCM approvals and is protected against short circuit, overload, over-voltage and over-temperature. Backed by a 5-year warranty.

Key Features

✓85~305Vac input range (277Vac available)
✓Global certificates in multi-fields(ITE 62368-1, Industrial 61558-1/-2-16, 61010) & Marine DNV, SEMI47, CID2 HazLoc approved
✓48mm ultra slim width
✓High efficiency up to 96% and no-load power dissipation 1W~3W by R.C.
✓200% peak power capability
✓600% transient peak current capability
✓Built-in active current sharing for parallel operation up to 1920W (3+1)
✓MODBus communication interface for control, setting, and monitoring
✓Built-in constant current limiting circuit
✓Protections: Short circuit / Overload / Over voltage / Over temperature
✓Fanless design, cooling by free air convection
✓Over voltage category III (OVC III)
✓-40°~+85°C wide range operation temperature (>+60°C derating)
✓Operating altitude up to 5000 meters
✓Built-in remote ON/OFF control and DC OK relay contact
✓Ultra low inrush current <6~15A
✓Tool free terminal block (LA Type)
✓Conformal coating
✓Can be installed on DIN rail TS-35/7.5 or 15
✓5 years warranty

Frequently Asked Questions

What is the output voltage and power rating of the Mean Well XDR-480-36?

The XDR-480-36 is rated for 36V output and 478.8W of power. Its rated output current is 13.3A, making it suitable for higher-power industrial DC supply requirements within those limits.

What types of applications is the XDR-480-36 intended for?

This model is designed for industrial DIN rail power applications where a 36V DC output and compact form factor are required. Its certifications cover multiple fields, including ITE, industrial, marine DNV, SEMI47, and CID2 hazardous location approval.

How slim is the XDR-480-36 compared with typical industrial DIN rail power supplies?

The XDR-480-36 has an ultra slim 48mm width. That makes it a strong fit for control cabinets or industrial panels where space efficiency is an important purchasing factor.

What temperature range does the XDR-480-36 support?

The specified operating temperature range for this model is -40°C to 85°C. This wide range supports demanding industrial environments where equipment may be exposed to low or elevated ambient temperatures.

Does the XDR-480-36 support parallel operation?

Yes. The product description lists built-in active current sharing for parallel operation up to 1920W in a 3+1 configuration.

What input voltage range is listed for the XDR-480-36?

The listed input range is 85~305Vac, with 277Vac availability noted in the product description. This broad AC input range supports use across many industrial power environments.

What efficiency is specified for the XDR-480-36?

The XDR-480-36 is specified with high efficiency up to 96%. The description also lists no-load power dissipation of 1W to 3W by R.C.

What warranty period and weight are listed for this model?

The XDR-480-36 has a listed warranty period of 5 years. Its listed weight is 1.1kg.
