Image shown is a representation only. Exact specifications should be obtained from the product datasheet.
Mean Well XDR-75-12 High-End Ultra Slim Industrial Din Rail Power S...
Please Login for Pricing
Description
Description
Key Features
- ✓85~305Vac input range (277Vac available)
- ✓Global certificates in multi-fields(ITE 62368-1, Industrial 61558-1/-2-16, 61010) & Marine DNV, SEMI47, CID2 HazLoc approved
- ✓30mm ultra slim width
- ✓High efficiency up to 91% and no-load power dissipation 0.7W~1W by R.C.
- ✓200% peak power capability
- ✓600% transient peak current capability
- ✓Built-in constant current limiting circuit
- ✓Protections: Short circuit / Overload / Over voltage / Over temperature
- ✓Fanless design, cooling by free air convection
- ✓Over voltage category III (OVC III)
- ✓-40°~+85°C wide range operation temperature (>+60°C derating)
- ✓Operating altitude up to 5000 meters
- ✓Built-in remote ON/OFF control and DC OK relay contact
- ✓Ultra low inrush current <6~15A
- ✓Tool free terminal block (LA Type)
- ✓Conformal coating
- ✓Can be installed on DIN rail TS-35/7.5 or 15
- ✓5 years warranty
Specifications
Specifications
-
BrandMean Well
-
Input Voltage85V~305V
-
Standards MetCB,CCC,CE,cUL,DEKRA,EAC,KC,RCM
-
Operating Temperature-40°C~85°C
-
Length11.6 cm
-
Width3 cm
-
Height12.52 cm
-
Weight0.5 kg
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
What output does the Mean Well XDR-75-12 provide?
The XDR-75-12 is a 74.88W DIN rail power supply with a 12V DC output. Its rated output current is 6.24A, making it suitable for industrial control and automation loads within that power range.
What types of applications is the XDR-75-12 intended for?
This model is designed for industrial DIN rail power supply applications where a slim 12V DC source is needed. Its listed approvals include ITE, industrial, marine DNV, SEMI47, and CID2 HazLoc, supporting use across demanding commercial and industrial environments.
How slim is the XDR-75-12 compared with standard DIN rail power supplies?
The XDR-75-12 has a 30mm ultra slim width. That makes it useful for panels where space is limited and a compact DIN rail power supply is preferred.
What operating temperature range does the XDR-75-12 support?
The specified operating temperature range is -40°C to 85°C. This wide range makes the model appropriate for many industrial environments where temperature conditions can vary significantly.
What input voltage range does the XDR-75-12 accept?
The XDR-75-12 supports an 85-305Vac input range. The product description also notes 277Vac availability, which can be important for industrial and commercial power systems.
What protection features are listed for the XDR-75-12?
The listed protections are short circuit, overload, over voltage, and over temperature. It also includes a built-in constant current limiting circuit.
Is the XDR-75-12 suitable for global industrial projects?
The XDR-75-12 lists global certifications across multiple fields, including ITE 62368-1, industrial 61558-1/-2-16, 61010, marine DNV, SEMI47, and CID2 HazLoc approval. Buyers should still confirm the required approvals for their specific project or region before purchase.
What warranty and weight are specified for the XDR-75-12?
The XDR-75-12 has a listed 5 year warranty period. Its specified weight is 0.496 kg.
