Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Mean Well XDR-960-36PI High-End Ultra Slim Industrial Din Rail Power Supply 957.6W 36V with Push In Connector 26.6A

96mm widthhigh efficiency up to 96%200% peak power capability600% transient peak current capabilityparallel operation up to 3840WMODBus communicationinrush current <10~23Aconformal coating

SKU XDR-960-36PI

Log in to see price Trade pricing & online ordering for account holders

Available to order

Overview

XDR-960-36PI is the 36V output model of this series: rated power 957.6W, typical efficiency 95.5%.

The XDR-960 series is a 960W AC/DC high-end ultra slim industrial DIN rail power. Key features of this series include a narrow 96mm casing, optimizing system installation space, and an ultra-wide input range of 85~305Vac suitable for global use. It boasts a maximum efficiency of 96% and a low standby power consumption 1.5W for energy savings and carbon reduction. It supports MODBus communication interface, provides constant current with up to 200% peak power, and can handle transient peak current of 600%. It has a fanless design, ultra-wide operating temperature range of -40 to +85℃ (up to +60℃ at full load); OVCⅢ compliance; parallel function capability up to 3840W; ultra-low inrush current of <10~23A, and includes DC OK and remote ON/OFF functions. It also has a built-in ORing FET, the internal PCB has a coating for basic moisture and dust protection, and it has multiple terminal blocks for selection. With comprehensive protection functions, complete safety certifications, and a 5-years warranty, the XDR-960 series is a compact, high-performance, and highly reliable DIN rail power supply.

Features

85~ 305Vac input with PFC (277Vac available)
Global certificates in multi-fields(ITE 62368-1,Industrial 61558-1/-2-16,61010) & Marine DNV,SEMI47,CID2 HazLoc approved
96mm ultra slim width
High efficiency up to 96% and no load power dissipation 1.5W by R.C.
Built-in MODBus RTU protocol
200% peak power capability
600% transient peak current capability
Built-in constant current limiting circuit
Current sharing up to 3840W (3+1) for parallel use
Protections: Short circuit / Overload / Over voltage / Over temperature
Fanless design, cooling by free air convection
Over voltage category Ⅲ (OVC Ⅲ)
-40~ +85℃ wide range operation temperature(>+60℃ derating)
Operating altitude up to 5000 meters
Built-in remote ON/OFF control and DC OK relay contact
Ultra low inrush current <10~23A
Built-in ORing FET
Tool free terminal block (LA Type)
Conformal coating
Can be installed on DIN rail TS-35/75 or15
5 years warranty

Specifications

XDR-960-36PISpecifications from the official datasheet (2026-06-05 edition)

OUTPUT

DC VOLTAGE: 36V
LOAD CURRENT RANGE: 0 ~ 26.6A
RATED POWER: 957.6W
PEAK CURRENT (5sec.): 53.3A
PEAK POWER (5sec.): 1920W
RIPPLE & NOISE (max.)^Note.2: 120mVp-p
VOLTAGE ADJ. RANGE: 36 ~ 42V
VOLTAGE TOLERANCE^Note.3: ±1.0%
LINE REGULATION: ±0.5%
LOAD REGULATION: ±1.0%
SETUP, RISE TIME: 1500ms, 100ms/277Vac 1500ms, 100ms/230Vac 1500ms, 100ms/115Vac at full load
HOLD UP TIME (Typ.): 20ms/277Vac 20ms/230Vac 20ms/115Vac at full load

INPUT

AC VOLTAGE RANGE: 85 ~ 305Vac
DC VOLTAGE RANGE: 80 ~ 431Vdc (Derating 50% Load @80Vdc)
NO LOAD CONSUMPTION(Typ.) Remote Power OFF: 1.5W@115Vac & 230Vac & 277Vac
NO LOAD CONSUMPTION(Typ.) Remote Power ON: 6.7W@115Vac 4.5W@230Vac & 277Vac
FREQUENCY RANGE: 47 ~ 63Hz
POWER FACTOR (Typ.): PF>0.98/115Vac PF>0.95/230Vac PF>0.9/277Vac at full load
EFFICIENCY (Typ.): 95.5%
AC CURRENT (Typ.): 10A/115Vac 5A/230Vac 4.2A/277Vac
INRUSH CURRENT (Typ.): COLD START 23A/115Vac 10A/230Vac 15A/277Vac
LEAKAGE CURRENT: <3.5mA / 240Vac <4.5mA / 277Vac

PROTECTION

OVERLOAD: 105%~200% rated output power for more than 5 sec then constant current limiting at rate current without shutdown when Vo=30%~100% Hiccup mode when Vo<30% rated voltage
OVER VOLTAGE: 43 ~ 50V Protection type : Shut down o/p voltage, re-power on to recover
OVER TEMPERATURE: Protection type : Shut down o/p voltage, recovers automatically after temperature goes down

FUNCTION

PARALLEL: Up to 3840W (3+1) units; Please refer to Function Manual for more details.
DC OK RELAY CONTACT: Relay Contact Ratings (max.):30Vdc/1A, 30Vac/0.5A resistive load
REMOTE CONTROL: Power ON :RC(Pin9) and 5V_AUX(Pin10) short . Power OFF:RC(Pin9) and 5V_AUX(Pin10) open. Please refer to Function Manual for more details.
MODBus INTERFACE: Communication provides functions such as control, setting, and monitoring.
TRANSIENT PEAK CURRENT CAPABLILTY: 600% rated current for 15ms

ENVIRONMENT

WORKING TEMP.: -40 ~ +85℃ (Refer to "Derating Curve")
WORKING HUMIDITY: 20 ~ 95% RH non-condensing
STORAGE TEMP., HUMIDITY: -40 ~ +85℃, 10 ~ 95% RH non-condensing
TEMP. COEFFICIENT: ±0.03%/℃ (0 ~ 60℃)
VIBRATION: Component:10 ~ 500Hz, 2G 10min./1cycle, 60min. each along X, Y, Z axes; Mounting: Compliance to IEC60068-2-6

SAFETY & EMC

SAFETY STANDARDS^Note.4&5&6: CB IEC62368-1, IEC61558-1/-2-16, IEC61010-1/-2-201 TUV BS EN/EN62368-1,BS EN/EN61558-1/-2-16,BS EN/EN61010-1/-2-201 UL UL121201/CSA C22.2 NO.213.17 Class I,DIV2 Group A,B,C,D Hazardous Locations T4;UL61010-1/-2-201 CCC GB4943.1 BSMI CNS15598-1 EAC TPTC004 Marine DNV (for GL type only) SEMI F47 approved KC/BIS KC62368-1 and BIS IS 13252 (Part 1) certified, No stock ,contact sales by request
OVER VOLTAGE CATEGORY^Note.7: IEC/EN 61558-1/-2-16 (OVC Ⅲ, altitude up to 2000m ) IEC/EN/UL 61010-1/-2-201 (OVC Ⅱ, altitude up to 5000m ) IEC/EN 62368-1 (OVC Ⅱ, altitude up to 5000m )
SAFETY EXTRA-LOW VOLTAGE(SELV): IEC/EN 61558-2-16 (SELV) IEC/EN 62368-1 (SELV / ES1 )
WITHSTAND VOLTAGE: I/P-O/P: 4KVac I/P-FG: 2KVac O/P-FG: 1.5KVac O/P-DC OK: 0.5KVac
ISOLATION RESISTANCE: I/P-O/P, I/P-FG, O/P-FG: 100M Ohms/500VDC/25℃/ 70%RH
EMC EMISSION: Parameter Standard Test Level

Conducted BS EN/EN55032 (CISPR32) / BS EN/EN61204-3 / CNS15936 / KS C 9832 Class B
Radiated BS EN/EN55032 (CISPR32) / BS EN/EN61204-3 / CNS15936 / KS C 9832 Class B
Harmonic Current BS EN/EN61000-3-2 Class A
Voltage Flicker BS EN/EN61000-3-3
EMC IMMUNITY: BS EN/EN55035 , BS EN/EN61204-3, BS EN/EN61000-6-2(BS EN/EN50082-2) ,KS C 9835,SEMI F47 tested at 200Vac

Parameter Standard Test Level

ESD BS EN/EN61000-4-2 Level 4, 15KV air; Level 4, 8KV contact; criteria A
Radiated BS EN/EN61000-4-3 Level 3, 10V/m; criteria A
EFT / Burst BS EN/EN61000-4-4 Level 4, 4KV; criteria A
Surge BS EN/EN61000-4-5 Level 4, 2KV/Line-Line ;Level 4, 4KV/Line-Line-Chassis ;criteria A
Conducted BS EN/EN61000-4-6 Level 3, 10V; criteria A
Magnetic Field BS EN/EN61000-4-8 Level 4, 30A/m; criteria A

Parameter	Standard	Test Level
Conducted	BS EN/EN55032 (CISPR32) / BS EN/EN61204-3 / CNS15936 / KS C 9832	Class B
Radiated	BS EN/EN55032 (CISPR32) / BS EN/EN61204-3 / CNS15936 / KS C 9832	Class B
Harmonic Current	BS EN/EN61000-3-2	Class A
Voltage Flicker	BS EN/EN61000-3-3

Parameter	Standard	Test Level
ESD	BS EN/EN61000-4-2	Level 4, 15KV air; Level 4, 8KV contact; criteria A
Radiated	BS EN/EN61000-4-3	Level 3, 10V/m; criteria A
EFT / Burst	BS EN/EN61000-4-4	Level 4, 4KV; criteria A
Surge	BS EN/EN61000-4-5	Level 4, 2KV/Line-Line ;Level 4, 4KV/Line-Line-Chassis ;criteria A
Conducted	BS EN/EN61000-4-6	Level 3, 10V; criteria A
Magnetic Field	BS EN/EN61000-4-8	Level 4, 30A/m; criteria A

OTHERS

MTBF: 819.6K hrs min. Telcordia SR-332 (Bellcore); 113.3K hrs min. MIL-HDBK-217F (25℃)
DIMENSION: 96*125.2*132mm (W*H*D)
PACKING: 2.06Kg; 6pcs/ 13.4Kg /1.49CUFT

Test conditions and notes8

1. All parameters NOT specially mentioned are measured at 230Vac input, rated load and 25℃ of ambient temperature.
2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1μF & 47μF parallel capacitor.
3. Tolerance : includes set up tolerance, line regulation and load regulation.
4. The power supply is considered a component which will be installed into a final equipment. The final equipment must be re-confirmed that it still meets EMC directives. (as available on https://www.meanwell.com//Upload/PDF/EMI_statement_en.pdf )
5. The Regulatory Compliance Mark (RCM) is applied on a voluntary basis. The equipment meets the relevant IEC or AS/NZS standards, or AS/NZS 3820 where applicable. The use of the RCM mark complies with AS/NZS 4417.1.
6. Some factory or model may not have the BIS logo, please contact your MEAN WELL sales for more information.
7. The ambient temperature derating of 3.5℃/1000m with fanless models and of 5℃/1000m with fan models for operating altitude higher than 2000m(6500ft).
8. Installation clearances : 40mm on top, 20mm on the bottom, 5mm on the left and right side are recommended when loaded permanently with full power. In case the adjacent device is a heat source, 15mm clearance is recommended.

Technical drawings

XDR-960-36PI Block Diagram — Block Diagram

XDR-960-36PI Derating Curve — Derating Curve

XDR-960-36PI P pk x t + Pnpk x (T-t) — P pk x t + Pnpk x (T-t)

XDR-960-36PI Transient peak current Capability — Transient peak current Capability

XDR-960-36PI Transient peak current Capability (2) — Transient peak current Capability (2)

XDR-960-36PI Function Manual — Function Manual

XDR-960-36PI 1.Parallel Use — 1.Parallel Use

XDR-960-36PI 2. Support MODBus Communication — 2. Support MODBus Communication

XDR-960-36PI 3.DC OK Relay Contact — 3.DC OK Relay Contact

XDR-960-36PI 3.DC OK Relay Contact (2) — 3.DC OK Relay Contact (2)

XDR-960-36PI 4.Remote ON/OFFControl — 4.Remote ON/OFFControl

XDR-960-36PI 4.Remote ON/OFFControl (2) — 4.Remote ON/OFFControl (2)

XDR-960-36PI 5.Protection Against Inverse Voltages From The Load — 5.Protection Against Inverse Voltages From The Load

XDR-960-36PI 6.LED Status Indictors — 6.LED Status Indictors

XDR-960-36PI Mechanical Specification — Mechanical Specification

Typical applications

Industrial control system
Semiconductor fabrication equipment
Factory automation
Electro-mechanical apparatus

Downloads

::specification::

FAQ

What output does the Mean Well XDR-960-36PI provide?

The XDR-960-36PI is rated for 957.6W of output power at 36VDC. Its rated output current is 26.6A, making it suitable for higher-power 36V industrial loads.

What types of applications is the XDR-960-36PI intended for?

This model is designed for industrial DIN rail power systems that require a compact, high-power 36V supply. Its listed approvals include ITE, industrial, marine DNV, SEMI47, and CID2 HazLoc, which supports use across demanding commercial and industrial environments.

How wide is the XDR-960-36PI?

The XDR-960-36PI has a 96mm width. That ultra-slim DIN rail format is a key differentiator for applications where panel space is limited.

What temperature range does the XDR-960-36PI support?

This model is specified for operation from -40°C to 85°C. That wide temperature range makes it appropriate for many harsh industrial environments where standard power supplies may not be suitable.

What input voltage range does the XDR-960-36PI support?

The product description lists an 85-305Vac input range, including 277Vac availability. This broad input range supports use in global industrial power systems.

What makes the XDR-960-36PI different from a basic DIN rail power supply?

Compared with simpler DIN rail supplies, the XDR-960-36PI offers higher-end features such as up to 95.5% efficiency, 200% peak power capability, and 600% transient peak current capability. It also includes MODBus communication for control, setting, and monitoring.

Can the XDR-960-36PI be used in parallel power systems?

Yes, the description lists built-in active current sharing for parallel operation up to 3840W in a 3+1 configuration. This makes it suitable for systems that require expanded power capacity or redundancy using compatible units.

What warranty and weight does the XDR-960-36PI have?

The XDR-960-36PI is listed with a 5-year warranty period. Its weight is 2.06kg, which is useful to know for panel planning and logistics.
