Can the APV-12-12 power a 12V LED strip for under-cabinet lighting?

Yes. The APV-12-12 outputs 12V at up to 1A, giving a maximum of 12W. It suits short runs of 12V LED strip in enclosed spaces such as under-cabinet or display-case lighting. Keep the total strip load at or below 12W.

How many meters of 12V LED strip can the APV-12-12 drive?

The APV-12-12 delivers 12W at 12V. Dividing 12W by your strip's rated power per meter gives the maximum length — for example, 12W ÷ 4.8 W/m equals about 2.5 m. Always check your strip's rated power per meter and derate to around 80% of the driver's capacity for reliable operation.

Is the APV-12-12 suitable for outdoor or damp-location use?

The APV-12-12 carries an IP42 rating, which protects against solid objects larger than 1 mm and dripping water falling at an angle up to 15°. It is not rated for direct outdoor exposure, rain, or splash environments. For outdoor or wet-location LED signage, a driver rated IP65 or higher is required.

How does the APV-12-12 differ from the APV-12-15 and APV-12-24 in the same wattage family?

All three share the same 12W power class and identical 77.0 × 40.0 × 29.0 mm housing. The APV-12-12 outputs 12V at 1A; the APV-12-15 outputs 15V at 0.8A; the APV-12-24 outputs 24V at 0.5A. Select based on the voltage your LED strip or luminaire requires.

What input voltage range does the APV-12-12 accept?

The APV-12-12 accepts 90–264VAC, covering standard mains voltages worldwide including 100V (Japan), 120V (North America), and 230–240V (Europe and Australia). No manual voltage switching is needed.

1 5

Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Mean Well

Mean Well APV-12-12 Power Supply 12W 12V 1A

4.6 (11 reviews)

Class II designlow costsmall and compactIP42

SKU APV-12-12

Log in to see price Trade pricing & online ordering for account holders

Select model — 5 in this family

APV-12-12

APV-8-12 8W 12V In stock

APV-12-12 12W 12V Low stock

APV-16-12 16W 12V Low stock

APV-25-12 25W 12V In stock

APV-35-12 35W 12V In stock

Product variants

Notify me when it's back in stock

The APV-12 is a 12W Mean Well AC-DC constant voltage LED driver (input: 90~264VAC, output: 12V, operating temperature: -30~+70°C).

Key Features

✓ Input voltage: 90~264VAC
✓ Output voltage: 12V
✓ Rated output current: 1A
✓ Class II design — no earth connection required
✓ Ingress protection: IP42
✓ Operating temperature: -30~+70°C
✓ Safety certifications: CB, CCC, CE, EAC, ENEC, UL
✓ 2 year warranty

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Model	Power	Voltage	Current	IP Rating
Mean Well APV-12-24 Power Supply 12W 24V 500mA	12W	24V	0.5A	IP42	View
Mean Well APV-12-5 Power Supply 10W 5V 2A	10W	5V	2A	IP42	View
Mean Well APV-12-15 Power Supply 12W 15V 800mA	12W	15V	0.8A	IP42	View

Customer reviews

4.6 Reviews verified for authenticity

5 ★ (8)

4 ★ (2)

3 ★ (1)

2 ★ (0)

1 ★ (0)

Reviewed by 11 customers across the APV series

Great for LED strip runs
By Tane W.|2026-06-20✓ Verified Buyer
Model: APV-35-24Quantity: 6
Used the APV-35-24 to drive 5m of warm-white strip — dead quiet, no flicker on dimming.
Compact and cool
By Priya S.|2026-06-05✓ Verified Buyer
Model: APV-25-24Quantity: 3
Fits our enclosures nicely. Runs slightly warm at full load but well within spec.
Reliable CV driver
By Workshop NZ|2026-05-12
Model: APV-16-24Quantity: 20
Standard part for our signage jobs now. Zero returns.
