Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Archilight Dot Mini 28 Track Light 5.3W - White + Gold

SKU KC-10.002A01-15D-3000K-WG

Log in to see price Trade pricing & online ordering for account holders

Configure — 8 variants

KC-10.002A01-15D-3000K-WG

LED Colour

Beam Angle

8 matching

Pick options to narrow the list, or tap a row to select. Dimmed chips have no matching combination.

Product variants

Available to order

Technical drawings

Archilight Dot Mini 28 Track Light 5.3W - White + Gold XS TRACK Mini A surface — XS TRACK Mini A surface

Archilight Dot Mini 28 Track Light 5.3W - White + Gold XS TRACK Mini A surface (2) — XS TRACK Mini A surface (2)

Archilight Dot Mini 28 Track Light 5.3W - White + Gold XS TRACK Mini A surface (3) — XS TRACK Mini A surface (3)

Archilight Dot Mini 28 Track Light 5.3W - White + Gold XS TRACK Mini O suspended — XS TRACK Mini O suspended

Archilight Dot Mini 28 Track Light 5.3W - White + Gold XS TRACK Mini O suspended (2) — XS TRACK Mini O suspended (2)

Archilight Dot Mini 28 Track Light 5.3W - White + Gold CURVED TRACK Mini AC — CURVED TRACK Mini AC

Archilight Dot Mini 28 Track Light 5.3W - White + Gold CURVED TRACK Mini AC (2) — CURVED TRACK Mini AC (2)

Archilight Dot Mini 28 Track Light 5.3W - White + Gold XS TRACK Mini A / Mini O / Mini T — XS TRACK Mini A / Mini O / Mini T

Downloads

Datasheet1

Archilight Dot Mini 28 Track Light 5.3W - White + Gold datasheetdot_28_spec_sheet.pdf PDF Download

FAQ

What type of lighting application is the Archilight Dot Mini 28 designed for?

The Archilight Dot Mini 28 is a compact track light made for minimalist interior lighting where the focus stays on the light effect rather than the fitting itself. Its ultra-thin Mini-series design suits dedicated spaces that need precise, low-visual-impact accent lighting.

What options are available across this parent product family?

This parent family includes beam angle options of 15, 24, 36, and 50 degrees. It is also offered in multiple colour temperature variants, including 3000K and 4000K, with additional variants in the range showing a broader tunable colour-temperature option.

How bright is the Archilight Dot Mini 28 Track Light?

The child variants in this family are rated at 461 lumens with a 5.3W power draw. That makes it suitable for focused accent and feature lighting within a low-profile magnetic track system.

What are the key technical specifications of this track light family?

This product family is rated at 5.3W, CRI 90, and 50,000 hours of lifetime, with a 5-year warranty. The parent model dimensions are 100 mm long, 28 mm wide, and 60 mm high, with a listed weight of 0.5 kg.

Is a driver included with the Archilight Dot Mini 28?

No, the product data for this family lists the driver as not included. It is specified for 48V power input, so it should be selected as part of a compatible 48V mini magnetic track system design.

Which track systems is the Archilight Dot Mini 28 intended to pair with?

The parent product description specifically pairs this light with Mini S Surface Tracks, Mini T Trimless Tracks, and Mini O Suspended Tracks. These pairings indicate it is intended for use within the Archilight Mini magnetic track family.

Is this track light dimmable?

No, the listed dimming control for this parent family is none. If dimming is a project requirement, that should be checked at the system-selection stage rather than assumed from this product alone.

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Model	Power	CRI	Dimming	UGR
Archilight Dot Mini 28 Track Light 5.3W - White	5.3W	90	None	19	View
Archilight Dot Mini 28 Track Light 5.3W - Black + Gold	5.3W	90	Non Dimmable	19	View
Archilight Dot Mini 28 Track Light 5.3W - Black	5.3W	90	None	19	View
