Envo

Envo EV-SNT-20-12 Super Thin LED Driver 20W 12V 1.67A

screw terminalultra thin
SKU EV-SNT-20-12
Log in to see price Trade pricing & online ordering for account holders
Log in or apply for a trade account →

Select model — 2 in this family

EV-SNT-20-12
In stock
|

Overview

EV-SNT-20-12 is the 12V output model of this series: rated current 0-1.67A, rated power 20W.

EV-SNT-20-12/24 is an indoor ultra thin constant voltage LED driver. Its input voltage range is180-264Vac, with a maximum conversion efficiency of 85%, working in the temperature range of -20°C~+45°C ambient temperature range. with high power factor, low THD, low standby power consumption and all round protection function, which not only greatly improves the reliability of the product, but also ensures the life cycle of product. The product completely in accordance with EN IEC 61000-3-2 THD standard. This series is designed for LED lighting and applied to indoor bathroom mirror lamp and other lighting fixtures

Features

  • Compliance to EN IEC 61000-3-2 <25W standard.
  • Screw terminals for easy installation.
  • Short circuit / overload / over-voltage protection.
  • Compliance to worldwide saftey regulations for lighting.
  • Lifetime: 30000 hours.

Specifications

EV-SNT-20-12Specifications from the official datasheetDownload datasheet PDF

Output

DC Voltage
12V
Voltage Tolerance
±5%
Rated current
0-1.67A
Rated power
20W

Input

Voltage Range
AC 180V - 264V
Frequency Range
50-60HZ
Power Factor
0.80 - 0.84
Full Load Efficiency (Typ.)
86%
AC Current (Max.)
0.17A/230V
Leakage current
0.7mA (230Vac/50HZ)

Protection

Short Circuit
Short circuit power ≤0.6W
Over load
1.5 times of rated output voltage

Environment

Working TEMP.
-20 - 45°C
Working Humidity
10%RH - 90%RH
Storage TEM.,Humidity
-40°C to 85°C, 5%RH - 95%RH
TEMP.coefficient
±0.03%/°C (0 ~ 60°C)

Safety&EMC

Safety standards
EN/IEC-61347, EN/IEC-60598 Approved, AS/NZS-61347/60598 Approved
Withstand voltage
Input-Output 3750V/5mA/1min
Isolation resistance
>5M Ohm/500VDC/25°C/70%RH
EMC EMISSION
Compliance to EN/IEC-55015, EN/IEC-61000, AS CISPR 15:2017
EMC immunity
Compliance to EN-61547:2009, EN-61000-4-2,3,4,5,6,11

Others

Weight
0.0765KG
Size
103*35.5*16mm (L*W*H)
Packing
200PCS

Notes

Warranty
5 years

Technical drawings

EV-SNT-20-12 Mechanical Specification
Mechanical Specification
EV-SNT-20-12 Mechanical Specification (2)
Mechanical Specification (2)
EV-SNT-20-12 Derating Curve
Derating Curve

Downloads

FAQ

What type of LED applications is the Envo EV-SNT-20-12 designed for?

The Envo EV-SNT-20-12 is a constant-voltage 12V LED driver intended for lighting applications that require a 12V DC power source. With a 20W power rating, it suits lower-power LED products where stable 12V output is required.

What are the main electrical specifications of the EV-SNT-20-12?

This model is rated for 20W output power with a 12V DC output. Its rated current is 1.67A, which makes it suitable for loads that match those output limits.

Does the Envo EV-SNT-20-12 support dimming?

No, this model does not include a dimming control function. It is intended for applications where a fixed 12V constant-voltage output is needed rather than adjustable light control.

What protection features are included in the EV-SNT-20-12?

The EV-SNT-20-12 includes short circuit and overload protection. These built-in protections help support safer operation in lighting systems using this specific driver.

What operating temperature range is specified for this LED driver?

This model is specified for ambient temperatures from -20°C to 45°C. That range makes it suitable for many indoor and protected lighting environments operating within those limits.

How does the EV-SNT-20-12 compare with higher-power 12V LED drivers?

The EV-SNT-20-12 is a lower-power option within the 12V constant-voltage category, with a 20W rating and 1.67A rated current. Compared with higher-wattage 12V drivers, it is better suited to smaller loads that do not require more output capacity.

What warranty and expected lifetime are listed for the EV-SNT-20-12?

This model carries a 5-year warranty period. Its listed lifetime is 30,000 hours, giving buyers a clear expectation for long-term lighting use.
